Specifications

Features
This modern design provides a dramatic look and features high quality LEDs.
Ideal use in hallways, entrances, restrooms and anywhere general lighting is needed.
Provides lighting in residential, commercial, and hospitality applications.
Mounts vertical or horizontal. Fixture mounts to rectangular 2” x 4“ wall box (not included).
Construction
Fabricated metal housing. Backplate is die formed 22-gauge steel and painted.
Finish
All exposed metal is painted white or black powder coated finish.
Diffuser
White acrylic.
Electrical
This unit it direct wired with a constant current LED driver rated for 120VAC.
Compatible with residential TRIAC and ELV dimming.
Lamping
Fixture includes an LED module producing:
15.5W = 1200 source lumens
23W = 1800 source lumens
Rated for 50,000 hrs., 90 CRI
3000K (CCT)
Certification
cETLus certified for damp locations.
ADA
Warranty
Specifications and dimensions
subject to change without notice.
DATE
LOCATION
PREPARED
BY
COMMENTS
CATALOG
NUMBER
QUANTITY
FIXTURE TYPE
Ordering Information:
White Black LED Lumens CCT H W D
15.5W 1200 3000K 13-1/2” 4” 3-1/2”
23W 1800 3000K 24” 4” 3-1/2”
LED Sconce
