Specifications

ManualsBrandsOrren Ellis ManualsBathroom Vanity LightingSalcedo 1-Light LED Vanity Light

Fixture Type:

Catalog Number:

Project:

Bathroom Sconce

Color Temp & CRI

Watt

LED Lumens

Delivered Lumens

Finish

DESCRIPTION

A beautiful bar of pure LED light radiates through the co-extruded acrylic

diffuser for brighter illumination, and an adjustable back plate adds

versatility to this design's many attributes. It's a clean modern sconce

anywhere you mount it.

FEATURES

• Conversion plate for 4" J box included

• Adjustable backplate

• Driver installed within the Junction Box, driver dimension: 2.76" x 1.26" x

1.18"

• 5 year warranty

SPECIFICATIONS

Color Temp:

3500K, 3000K, 2700K

Input:

120-277 VAC, 50/60Hz

CRI:

Dimming:

ELV: 100 - 5%

Rated Life:

85000 Hours

Mounting:

Can be mounted on wall in all orientations

Standards:

ETL, cETL, Energy Star 2.0

Damp Location Listed

Construction:

Aluminum hardware with co-extruded acrylic

diffuser

FINISHES

Brushed

Aluminum

Brushed

Black

Brushed

Brass

LINE DRAWING

Size

12" 2700K 90 10.5W 863 779 Brushed Aluminum

3000K 90 10.5W 905 791 Brushed Black

3500K 90 10.5W 935 840 Brushed Brass

❍

Summary of content (4 pages)

PAGE 1
Fixture Type: Catalog Number: Project: Bathroom Sconce ❍ Size 12" Color Temp & CRI ❍ 2700K 90 ❍ 3000K 90 ❍ 3500K 90 Watt 10.5W 10.5W 10.5W LED Lumens 863 905 935 Delivered Lumens 779 791 840 ❍ ❍ ❍ Finish Brushed Aluminum Brushed Black Brushed Brass DESCRIPTION A beautiful bar of pure LED light radiates through the co-extruded acrylic diffuser for brighter illumination, and an adjustable back plate adds versatility to this design's many attributes. It's a clean modern sconce anywhere you mount it.
PAGE 2
Fixture Type: Catalog Number: Project: Location: Bathroom Sconce ❍ Size 18" Color Temp & CRI ❍ 2700K 90 ❍ 3000K 90 ❍ 3500K 90 Watt 15.5W 15.5W 15.5W LED Lumens 1155 1225 1330 Delivered Lumens 910 1015 1115 Finish ❍ Brushed Aluminum ❍ Brushed Black ❍ Brushed Brass DESCRIPTION A beautiful bar of pure LED light radiates through the co-extruded acrylic diffuser for brighter illumination, and an adjustable back plate adds versatility to this design's many attributes.
PAGE 3
Fixture Type: Catalog Number: Project: Location: Bathroom Sconce ❍ Size 24" Color Temp & CRI ❍ 2700K 90 ❍ 3000K 90 ❍ 3500K 90 Watt 20.5W 20.5W 20.5W LED Lumens 1595 1720 1785 Delivered Lumens 1330 1440 1510 Finish ❍ Brushed Aluminum ❍ Brushed Black ❍ Brushed Brass DESCRIPTION A beautiful bar of pure LED light radiates through the co-extruded acrylic diffuser for brighter illumination, and an adjustable back plate adds versatility to this design's many attributes.
PAGE 4
Fixture Type: Catalog Number: Project: Bathroom Sconce ❍ Size 36" Color Temp & CRI ❍ 2700K 90 ❍ 3000K 90 ❍ 3500K 90 Watt 30W 30W 30W LED Lumens 2365 2445 2561 Delivered Lumens 1985 2095 2180 Finish ❍ ❍ ❍ Brushed Aluminum Brushed Black Brushed Brass DESCRIPTION A beautiful bar of pure LED light radiates through the co-extruded acrylic diffuser for brighter illumination, and an adjustable back plate adds versatility to this design's many attributes. It's a clean modern sconce anywhere you mount it.
