SN OUTDOOR TOWER HEATER STREETWALKER o Standard 20 {b.
PRISM PATIO HEATER & DANGER If you smell gas: 1. hut off gas to the appliance 2. Extinguish any open flame, 3. If odor continues, keep away from the appliance and immediately call you gas supplier or fire department. & WARNING WARNING indicates an imminently hazardous situation which, if ot avoided, will result i death or serous injury.
PACKAGE CONTENTS Gas Hose & Regulator Front Panel Handle Handle Support Ceramic Fiber Reflector Mesh Glass Tube Fixer Top Plate Support Protective Guard Glass Tube Black Silicone Ring Control Box Ass Side Panel Block Belt Wheel Danial ol balalaika Aée Top Plate ? ” Support —° Protective Guard e Glass Tube .
HARDWARE CONTENTS {(shown actual size) @& Wingnut G /\ Malt flat Qty. 3 ./ washer #8 Q.6 Bolt M6 X 10 Qty. Wrench Qty. 1 A\ safety INFORMATION Please read and understand this entire manual before attempting fo assemble, operate or install the product. This manual contains important information about the assembly, operation and maintenance of this patio heater. General safety information is presented in these first few pages and is also located throughout the manual.
A\ safety INFORMATION DANGER " EXPLOSION FIRE HAZARD " Keep solid combustibles, such as building materials, paper or cardboard, a safe distance away from the heater as recommended by the instructions, " Provide adequate clearances around air openings into the combustion chamber. “Never use the heater in spaces which do or may contain volatile or airborne combustibles, or products such as gasoline, solvents, paint thinner, dust particles or unknown chemicals.
SAFETY INFORMATION I KARENINA California Proposition 65 Combustion by-products reduced when using this product contain chemicals known ta the State of California to cause cancer, birth defects, and other reproductive harm. BURN HAZARD ® Never leave heater unattended when hot or in use. > Keep out of reach of children. & WARNING Certain materials or items, when stored under the heater, will be subjected 1o radiant heat and could be seriously damaged. & WARNING & WARNING This product is fueled by propane gas.
ASSEMBLY INSTRUCTIONS 1. Heater is reassembled at the factory. User needs to complete a couple of assembly procedures to make the appliance operational. Please ensure all transit protection 7 i {foam, cardboard, bubble wrap, etc) is removed ,5“»2 in the next few steps you will be shown how to ,;j properly remove the bubble wrap material used to protect the oscillate glass tube s i, 7 located in the center of the unit.
ASSEMBLY INSTRUCTIONS 3. You will need to remove at least one of the protective steel guards (E} in order to safely remove the bubble rap material from the oscillate glass tube located in the center of the unit. Unscrew 1 of the M5x12 screws and 1 of the fixing brackets (GG), then remove the protective steel guard from its upper supports slots. Hardware Used P @ scewmsxiz \LMM %3 x3 @ Fixing Bracket /0 Philips @ screwdriver €= 4.
ASSEMBLY INSTRUCTIONS 5. Now that you have properly and carefully removed all transit protection materials from the unit, you will need to pace the unit back in its original proper order. We will revisit the last several steps in reverse order. First, re-install the oscillate glass tube (F). Carefully install the oscillate glass tube between center of the top plate and the contra box assembly as illustrated.
ASSEMBLY INSTRUCTIONS 7. Lean the heater carefully. install PCs studs (CC} on the top plate, secure them with PCs M8 cap nuts (I1). Assemble the mesh base to the stud, secure them with PCs M8 nuts (HH). Secure the mesh to the mesh base with PCs Screw M5X12(DD). Hardware Used swd (T QU0 x3 Nut M8 57 x3 Cap nut 066 Screw M5 X 12 ‘J?Mfig X3 o . Use a secured step ladder or lean the heater carefully and attach the PCs small flat washer #8 (BB} on top of the heater.
ASSEMBLY INSTRUCTIONS 9. Open the side panel, assemble the wheel assembly to the bottom plate using PCs M6x10 screws {CC). Hardware Used @ soil o x8 ~ Wrench 10.Open the front panel, and then open the lid of the battery compartment and insert 2 batteries type D (flashlight batteries DC1.5v each) considering the correct polarity.Close the lid.Return the side panel in place.
ASSEMBLY INSTRUCTIONS A dented, rusted or damaged propane cylinder may be hazardous and should be checked by your cylinder supplier. Never use a propane cylinder with a damaged valve connection. The propane cylinder must be constructed and marked in accordance with the specifications for LP gas cylinders of the U.8.
OPERATION INSTRUCTIONS Leak Check & WARNING * Perform all leak tests outdoors. « Extinguish all open flames. « NEVER leak test when smoking. « Do not use the heater unfit all connections have been leak tested and do not leak. Hose / Regulator connection Regulator / Cylinder connection 1. Make 2-3 oz. of leak check solution (one part liquid dish washing detergent and three parts water). 2. Apply several drops of solution where hose attaches to regulator. 3.
OPERATION INSTRUCTIONS & DANGER + CARBON MONOXIDE HAZARD ~ For outdoor use only. Never use inside house, or other ventilated or enclosed areas. This heater consumes air {oxygen). Do not use in ventilated or enclosed areas to avoid endangering your life. Caution: Do not attempt to operate until you have read and understand all General Safety Information in this manual and all assembly is complete and leak checks have been performed. Before Turning Gas Supply ON: 1.
OPERATION INSTRUCTIONS 4. Press the DOWN button to switch to lower temperature setting and UP button to switch to higher temperature setting. TO TURN OFF THE HEATER 1. Press the POWER button. 2. Turn off the valve of the gas cylinder and disconnect the cylinder. WARNING: 1. The whole gas system, hose, regulator, pilot or burner should be inspected for leak before use. 2. Check the hose assembly for sign of extreme abrasion, cuts or wears.Leak test suspected areas.
OPERATION INSTRUCTIONS FOR YOUR SAFETY FOR YOUR SAFETY Be careful when attempting to manually ignite this Heater will be hot after use. Handle with extreme care. heater. Holding in the control knob for more than 20 seconds before igniting the gas will cause a bail of flame upon ignition. When heater is ON: The flame should be blue with straight yellow tops. If excessive yellow flame is detected, turn off heater and consult “Troubleshooting” on page 18. B.
OPERATION INSTRUCTIONS 9. Heater is away from gasoline or other flammable liquids or vapors. 10. Heater is away from windows, air intake openings, sprinklers and other water sources. 11. Heater is at least 24 in. on top and at least 36 in. on sides from combustible materials. 12. Heater is on a hard and level surface. 13. There are no signs of spider or insect nests. 14. Al burner passages are clear. 186. All air circulation passages are clear. 16.
CARE AND MAINTENANCE * Gas odor with extreme yellow tipping of flame. * Heater does NOT reach the desired temperature. * Heater glow is excessively uneven. * Heater makes popping noises. * Spiders and insects can nest in burner or orifices. This dangerous condition can damage heater and render it unsafe for use. Clean burner holes by using a heavy-duty pipe cleaner. Compressed air may help clear away smaller particles. * Carbon deposits may create a fire hazard.
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE Cylinder valve is closed CORRECTIVE ACTION Open valve Blockage in orifice or pilot wbe Clean or replace artifice or piton tube Pilot won't light Airing gas line Open gas line and bleed it {pressing control knob in} for no more than 1 2 minutes or until you smell gas Note: Heater operates at reduced efficiency Low gas pressure with cylinder naive fully open Turn cylinder valve OFF and replace cylinder below 40°F (5°C) Ignite fails Use match to light pilot; obtain new ig
REPLACEMENT PARTS LIST Reflector e Mesh ” Support [ Protective Guard e Glass Tube € sk Si icons Ring o Control Box Says N/ @ dice Pearl i © sickbed " Wheel 79 Gas Hose & Regulator Front Panel 4 @ Bottom plate Handle v Handle Support Ceramic Fiber PART DESCRIPTION QUANTITY Reflector M Bottom plate 1 Mesh N Gas Hose & Regulator 1 Glass Tube Fixer O Front Panel 2 Top Plate P Handle 2 Support Q | Handle Support 4 Protective Guard R Ceramic Fiber 1 Glass Tube Black Silicone Rin Control Box Says Side Pane! Block
3/2/1 YEAR LIMITED WARRANTY Outdoor Order™ LLC warrants to'the original retail purchases of this heater, that if assembled-and operated in accordance with this printed instructions accompanying it; the mechanical operation of the heater for-a period of three years. Outdoor Order™ ELC warrants that powder coat finishes will be free from corrosion for a period of twa years, and metallic finishes for a period of one bear.
Dear Valued Customer, Thank you for your recent purchase from Outdoor Order™ LLC. We pride ourselves on providing innovative, reliable and stylish outdoor comfort products. Our mission is simple, “bring order to the outdoors”. Our collection meets rigorous manufacturing standards and is backed by a comprehensive warranty.
