OWNER'S MANUAL 93CM CORDLESS REMOTE LCD TV/MONITOR MODEL: TFTV930 N111 PALSONIC CORPORATION PTY LTD 1 JOYNTON AVENUE WATERLOO NSW 2017 AUSTRALIA TEL: (02) 9313 7111 FAX: (02) 9313 7555 www.palsonic.com.
Table of Contents Important Safety Precautions ................................................................................. 1 Remote Control ...................................................................................................... 4 Identification of Controls ......................................................................................... 7 Connections ........................................................................................................... 9 Basic Operation ....
Important Safety Precautions Electrical energy can perform many useful functions, but it can also cause personal injuries and property damage if improperly handled. This product has been engineered and manufactured with the highest priority on safety. But IMPROPER USE CAN RESULT IN POTENTIAL ELECTRICAL SHOCK OR FIRE HAZARD. In order to prevent potential danger, please observe the following instructions when installing, operating and cleaning the product.
Important Safety Precautions (continued) 12. Stand --- Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. Do not place the product on an unstable trolley, stand, tripod or table. Placing the product on an unstable base can cause the product to fall, resulting in serious personal injuries as well as damage to the product. When mounting the product on a wall, be sure to follow the manufacturer's instructions.
Important Safety Precautions (continued) 22. Power source --- This product is intended to be supplied by a listed power supply indicated on the marking label. If you are not sure of the type of power supply to your home, consult your product dealer or local power company. For added protection for this product during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the cable system.
Remote Control Remote Control 1. POWER Turn the unit on or off 2. Auto To adjust picture automatically in VGA mode 1 9 2 10 11 3 4 5 6 7 8 12 13 14 3. PBP To activate picture-by-picture 4. P.S. To select signal source for PIP frame 5. PIP To activate picture-in-picture 6. POS To adjust PIP frame position 7. Menu To access the Menu main page or exit menu operation 8.
Remote Control (continued) Remote Control 15. Source To access source select menu 16. S-SYS Sound system select 17. C-SYS Colour system select 18. S. Mode Sound mode select 19. P. Mode Picture mode select 20. 0-9 number buttons Direct channel select 15 21 16 22 17 18 19 23 24 25 21. Mute Sound mute 22. NICAM To select sound multiplex mode 23. SRS To turn on or off the SRS sound effect* 24. Headphone To output sound from headphone 20 26 27 25. Speaker To output sound from speaker 26.
Remote Control (continued) Using the Remote Control Use the remote control by pointing it towards the remote sensor window of the set. Objects between the remote control and sensor window may prevent proper operation. Note: the illustration is for your reference only, the remote sensor may locate differently with different model. Cautions regarding use of remote control Do not expose the remote control to shock.
Identification of Controls Main Unit Front view Bottom view Power Indicator A blue indicator lights when the power is on and a red indicator lights when in the standby mode. Headphone jack Power Switch Remote Sensor 1 2 4 3 5 1. SOURCE To access signal source select menu. 2. Menu Press this button to access the Menu main page. 3. CH+/-: menu navigation buttons In OSD Menu, press these buttons to choose the OSD items. 4.
Identification of Controls (continued) Main Unit Push downward and then pull out the cover carefully in the direction of the arrow to remove the cover. Push downward and then pull out the cover carefully in the direction of the arrow to remove the cover. Back view After all connections are made, aim the Insertion tabs toward the Locating grooves, then carefully push the Cover until it locks in place with a click. Side view Bottom view AUDIO AUDIO 3 4 5 1 2 1.
Connections Antenna Connection Optimum reception of colour requires a good signal and will generally mean that an outdoor aerial must be used. The exact type and position of the aerial will depend upon your particular area. Note: It is recommended that the 75-ohm coaxial cable be used to eliminate interference and noise which may occur due to radio wave conditions. The aerial cable should not be bundled with the power cord and the like.
Connections (continued) Cautions Before Connecting Carefully check the terminals for position and type before making any connections. The illustration of the external equipment may be different depending on your model. Loose connectors can result in image or colour problems. Make sure that all connectors are securely inserted into their terminals. Refer to the operating manual of the external device as well. When connecting an external device, turn the power off on the panel to avoid any issues.
Connections (continued) Connect a Camcorder AUDIO AUDIO Bottom view Video cable Audio cable AV OUT S-VIDEO IN /AV1 INPUT /AV2 INPUT Y W R Yellow (VIDEO) White (AUDIO L) Red (AUDIO R) Camcorder, etc. How to connect: Connect the Audio/Video cables between the Audio (L/R)/Video jacks on the unit and camcorder. To playback Camcorder 1. Turn on your LCD TV , press Source button on the remote control. 2. Press CH+ or CH- to select Video2 and press Enter to confirm. 3.
Connections (continued) Connect a DVD Player (or Set-Top Box) Y Pb Pr AUDIO R AUDIO L Video cable Audio cable White (audio L) Side view Red (audio R, Pr/Cr) Green (Y) Blue (Pb/Cb) Audio cable Video cable DVD player, Set-top Box etc. How to connect a DVD Player (or Set-Top Box) using Component Video Connections: Connect the Video cable between the Y, Pb, Pr input jacks on the unit and Pb, Pr output jacks on the DVD player (or Set-Top Box).
Connections (continued) Connect a DTV receiver Side view D-Sub AUDIO DVI cable DVI-D Audio cable AUDIO DTV receiver, etc. How to connect: 1. Connect the cable or antenna to the antenna input jack on the DTV receiver. 2. Connect the DVI cable between the DVI input interface on the unit and DVI output interface on the DTV receiver. 3. Connect the Audio cable between the AUDIO input jack on the unit and AUDIO output jacks on the DTV receiver. To Watch DTV 1.
Connections (continued) Connect a PC Side view D-Sub AUDIO VGA cable Audio cable DVI-D AUDIO Computer or other equipment with VGA interface How to connect: Connect a VGA cable between the VGA jack on the PC and the D-Sub VGA input jack on the unit. Connect an Audio cable between the AUDIO output on the PC and AUDIO input jack on the unit. To Watch the PC screen 1. Turn on your LCD TV, press Source button on the remote control. 2. Press CH+ or CH- to select VGA. 3. Press Enter to confirm. 4.
Connections (continued) To connect AV output terminal AUDIO AUDIO Bottom view AUDIO AUDIO Y W R Audio cable Yellow (VIDEO) White (AUDIO L) Red (AUDIO R) Audio amplifier VCR for recording How to connect: Connect the Audio/Video cables between the Audio (L/R)/Video jacks on the unit and VCR. Or connect the Audio cable between the Audio (L/R) jacks on the unit and Audio amplifier. How to record program 1. Turn on your LCD TV select a program you wish to record. 2.
Basic Operations Turning the Unit On and Off Turning On Insert the power cord into the wall outlet. Press the Power Switch on the TV set, the set is in standby mode. Press the Power button on the remote control. The unit will be turned on and you will be ready to use it's features. Turning Off With the power on, press the Power button on the remote control to turn off the TV set temporarily. If you want to cut off the power completely, press the Power Switch on the TV set.
Tuning In Auto Search 1 Press Menu to display the menu main page. Channel No. Add/Erase Auto Search Manual Search Fine Tune Sound System Color System Channel Swap AFC 2 Press CH+ or CH- repeatedly to select CH item. 3 Press Enter to access the submenu. 4 Press CH- repeatedly to highlight Auto Search item. 5 Press Enter to store channels in memory automatically. The unit will begin memorising all the available channels. During the process of the Auto Search, you can press Menu to exit.
Tuning In (continued) AFC (Auto Frequency Control) 1 Press Menu to display the menu main page. Channel No. Add/Erase Auto Search Manual Search Fine Tune Sound System Color System Channel Swap AFC On 2 Press CH+ or CH- repeatedly to select CH item. 3 Press Enter to access the submenu. 4 Press CH+ or CH- repeatedly to select AFC item. 5 Press Enter to toggle On or Off. When the AFC is set to On, the unit will automatically tune the program frequency to provide the best picture and sound.
Tuning In (continued) Add/Erase 1 Press Menu to display the menu main page. 2 Press CH+ or CH- repeatedly to select CH item. 3 Press Enter to access the submenu. 4 Press CH- to highlight Channel No item. 5 Channel No. Add/Erase Auto Search Manual Search Fine Tune Sound System Color System Channel Swap AFC Erase Press VOL+ or VOL- to select the program number you want to add or erase. 6 Press CH- to highlight Add/Erase item. 7 Press Enter to toggle Add or Erase.
Tuning In (continued) Sound System 1 Press Menu to display the menu main page. Channel No. Add/Erase Auto Search Manual Search Fine Tune Sound System Color System Channel Swap AFC 1 2 Press CH+ or CH- repeatedly to select CH item. 3 Press Enter to access the submenu. 4 Press CH+ or CH- repeatedly to select Sound System item. 5 Press Enter to select a proper sound system. 6 Press Menu to exit. 7 You could press S-SYS to select a proper sound system directly.
Selecting the Channels Direct Accessing Channels Press the number buttons to go directly to a channel. To select a one-digit channel: press the 0-9 number buttons directly. To select a two-digit channel: press -/-- and display -- , then input the number. Note: Be sure to enter the channel within 3 seconds. When you use the number buttons, you can directly select channels that were erased. Using the Channel Buttons (CH+ or CH-) Press the CH+ or CH- to change channels.
Setting Picture Customising the Picture 1 Press Menu to display the menu main page. The picture menu page will be displayed automatically. 2 3 4 5 Press Enter to access the Picture submenu. Color Brightness Contrast Sharpness Tint Press CH+ or CH- to select the item you wish to change. Press VOL+ or VOL- to adjust the value of the item. Press Menu to exit. Operation Function Option Range VOL+: deeper VOL-: paler VOL+: lighter VOL-: darker 0-100 Adjusts images contrast.
Sound Setting Customising the Sound 1 2 3 4 5 Press Menu to display the menu main page. Volume Bass Treble Balance Mute Speaker Head Phone AVC Press CH+ or CH- repeatedly to select Sound item. Press Enter to access the submenu. Press CH+ or CH- repeatedly to select the option items you want to adjust. Press VOL+ or VOL- to adjust the value or Enter to toggle settings. Function Option Volume Operation VOL+: stronger Adjusts volume value.
Sound Setting (continued) Setting SRS Effect Use the SRS button to quickly turn on or off the SRS effect. SRS (Sound Retrieval System®) is an audio enhancement technology that restores the spatial cues that are present in a live listening environment and processes it to provide a natural 3D sound field. * The SRS symbol is a trademark of SRS Labs, Inc. SRS technology is incorporated under license from SRS Labs, Inc.
Adjusting the OSD Selecting a Menu Language 1 2 3 Press Menu to display the menu main page. Press CH+ or CH- repeatedly to select OSD item. Language H Position V Position Halftone Zoom OSD off Default English Press Enter to access the submenu. The Language item will be highlighted automatically. 4 5 Press Enter to toggle between English and . Press Menu to exit. Adjusting OSD Position 1 2 3 4 5 Press Menu to display the menu main page. Press CH+ or CH- repeatedly to select OSD item.
Setting System In TV Mode Adjusting Screen Aspect 1 2 3 Press Menu to display the menu main page. 4 Press Enter repeatedly to select a desired aspect ratio. 16:9 You can select the image aspect ratio between 4:3, Panorama, Zoom and 16:9. 4:3 - For 4:3 signal format. This mode displays a 4:3 picture at its standard 4:3 size without any stretching. 16:9 - For 16:9 signal format. This mode displays 16:9 aspect ratio picture.
Setting System In YPbPr Mode Adjusting Phase 1 2 3 Press Menu to display the menu main page. 4 Press VOL+ or VOL- repeatedly to adjust the value. Phase Screen N/R Default Press CH+ or CH- repeatedly to select Setup item. Press Enter to access the submenu. The Phase item will be highlighted automatically. Adjusting Screen Aspect 1 2 3 4 5 Press Menu to display the menu main page. Phase Screen N/R Default Press CH+ or CH- repeatedly to select Setup item. Press Enter to access the submenu.
Setting System In DVI Mode 1 2 3 4 5 Press Menu to display the menu main page. The picture menu page will be displayed automatically. Brightness Contrast Sharpness Color Temp Press Enter to access the Picture submenu. Press CH + or CH- to select the item you wish to change. Press VOL+ or VOL- to adjust the value of the item. Press Menu to exit. Operation Function Option Range Brightness Adjusts screen brightness for easier viewing of dark picture such as night scenes and black hair.
Setting System In VGA Mode Operating System Menu 1 2 3 4 5 Press Menu to display the menu main page. H Position V Position Clock Phase Auto Adjust Resolution Default Press CH+ or CH- repeatedly to select Setup item. Press Enter to access the submenu. Press CH+ or CH- to select menu item. Press VOL+ or VOL- to adjust the value of the item. Item H Position V Position Clock Operation Function Adjusting the horizontal position of the screen. Adjusting the vertical position of the screen.
PIP Operations The PIP function is available only when the main frame is in VGA/DVI mode and the aspect ratio is in 16:9 and the vertical frequency is 60 Hz. Viewing the PIP 1 2 3 Press Menu to display the menu main page. 4 Press Enter to select On or Off. PIP Source H Position V Position Size PBP Press CH+ or CH- repeatedly to select PIP item. Press Enter to access the submenu. The PIP item will be highlighted automatically.
PIP Operations (continued) Changing the Position of the PIP Frame 1 2 3 4 5 Press Menu to display the menu main page. Press CH+ or CH- repeatedly to select PIP item. Press Enter to access the submenu. Press CH+ or CH- repeatedly to select H Position or V Position item. PIP Source H Position V Position Size PBP Press VOL+ or VOL- to adjust the PIP frame position. Main frame PIP frame Adjusting the Size of PIP Frame 1 2 3 4 5 Press Menu to display the menu main page.
Troubleshooting Before calling for repair service, check the following items for possible remedies to an encountered symptoms. Symptoms Check item "Ghost" or double images This may be caused by obstruction to the antenna due to high rise buildings or hills. Using a highly directional antenna may improve the picture. No power Check that the AC power cord is plugged into the mains socket. Unplug the power cord, wait for 60 seconds. Then reinsert plug into the mains socket and turn on the unit again.
Specifications TV Unit Dimension (WxHxD) (mm) 1135 x 588 x 120 TV Unit Dimension (WxHxD) (mm) with Stand 1135 x 652 x 250 Power Supply AC 100-240V 50/60Hz Power Consumption 200W Weight (kg) TV unit with Stand 28 Resolution 1366 x 768 Pixel Pitch 0.600 X 0.
PALSONIC CORPORATION PTY LTD 1 JOYNTON AVENUE WATERLOO NSW 2017 AUSTRALIA TEL: (02) 9313 7111 FAX: (02) 9313 7555 www.palsonic.com.au PALSONIC CUSTOMER SERVICE TELEPHONE AUSTRALIA: 1300 657 888 604-L37K73-02 Ver. 1.
