Replacing Consumables
54
1
Adding Paper
■■
■■
■ Paper Tray (1550-Sheet Paper Tray 1)
● Paper Weight: 16-24 lb
● Paper Capacity: 1550 Sheets (20 lb)
■■
■■
■ System Console (550-Sheet Paper
Tray 2-4)
● Paper Weight: 16-24 lb
● Paper Capacity: 550 Sheets (20 lb)
1
2
2
33
44
Open
Max Level Indicator
Close
Max Level Indicator
Close
Open
