Replacing Consumables
64
■■
■■
■ Replacing the Battery
Replacing the Battery
1
2
3
The copier has an internal battery (Product No.: CR2032) which maintains the date and time.
In the event, the battery requires replacement, the following message will be displayed.
The service life of the battery is approximately 1 year under normal use.
● THIS PRODUCT CONTAINS A LITHIUM BATTERY. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE.
IMPROPER USE OR REPLACEMENT MAY CAUSE OVERHEATING, RUPTURE OR EXPLOSION RESULTING IN
INJURY OR FIRE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS OF YOUR LOCAL
WASTE OFFICIALS AND LOCAL REGULATIONS.
● Be sure to use the specified type of battery only.
● Ensure that the battery is installed with correct polarity.
● Keep the battery away from small children.
■■
■■
■ Notice: California only:
This product contains a CR Coin Cell Lithium Battery which contains Perchlorate Material - special handling may apply.
See www.dtsc.ca.gov/hazardouswaste/perchlorate
WARNING
!
Open the Front Cover.
Remove the Screw and Holder.
Reinstall the Holder and Screw.
1
2
NOTE
● Battery Holder is placed behind the print data
LED.
CAUTION
!
