Specifications
Type Semi Console
Platen Type Fixed
Acceptable Original Sheets, Books (max. Ledger)
Copying Method Laser Electrophotography
Fixing Method Heat Roller Fixing
Imaging Method Dry-Type Two components imaging
Resolution Maximum: 600 dpi
Operation Panel Touch Panel Display
Maximum Copy Size Ledger - Invoice via Paper Tray
Void Area Max. 0.2" (5 mm)
Warm Up Time DP-8060/8045 : Approx. 180 seconds (68 °F/20 °C)
DP-8035 : Approx. 30 seconds (68 °F/20 °C)
First Copy Time DP-8060 : Approx. 3.5 seconds
(Letter
, from 1st Tray, platen) DP-8045 : Approx. 4.5 seconds
DP-8035 : Approx. 5.8 seconds
Multi-Copy Speed DP-8060 : 60 cpm (Letter size)
DP-8045 : 45 cpm (Letter size)
DP-8035 : 35 cpm (Letter size)
Enlargement Ratios Preset: 121 %, 129 %, 155 %, 200 %
Variable: from 101 - 400 % in 1 % increments
Reduction Ratios Preset: 79 %, 77 %, 65 %, 61 %, 50 %
Variable: from 99 - 25 % in 1 % increments
Paper Feed Paper Tray (1550 sheets + 550 sheets) + Sheet Bypass (50 sheets)
+ System Console (1100 sheets)
Paper Weight Paper Tray: 16 - 24 lb (Bypass: 15 - 35 lb)
Quantity Selector Maximum: 999 sheets (Optional Exit Tray capacity is 250 sheets)
Electrical Consumption 120 V AC, 60 Hz, 12 A
Energy Consumption Less than 1.45 kW
Dimensions (W x D x H) 23.6" (W) x 29.8" (D) x 35.4" (H) (600 x 757 x 900 mm)
Weight DP-8060/8045 : 302 lb (137 kg)
DP-8035 : 295 lb (134 kg)
Operating Environment Temperature: 50 - 86 °F (10 - 30 °C); Relative Humidity: 30 - 80 %
(However, the humidity should be 70 % or less at a temperature of 86 °F (30 °C),
and the temperature should be 80 °F (27 °C) or less at a humidity level of 80 %.)
● Specifications are subject to change without notice.
DP-8060/8045/8035 (Copier)
Modes Power Consumption Warm Up Time
(Measured 68 °F/20 °C)
Power Saver Mode DP-8060 : Approximately 200 W
DP-8045 : Approximately 190 W DP-8060/8045/8035 : Min. 30 sec. recovery
DP-8035 : Approximately 60 W
Sleep Mode Approximately 35 W DP-8060/8045 : 180 sec. recovery
DP-8035 : 30 sec. recovery
Shutdown Mode Below 4 W DP-8060/8045 : 180 sec. recovery
DP-8035 : 30 sec. recovery
