Appendix
66
Printer Unit
*
1
Microsoft
®
Windows
®
98 operating system *
2
Microsoft
®
Windows
®
Millennium Edition operating system
*
3
Microsoft
®
Windows NT
®
operating system Version 4.0 *
4
Microsoft
®
Windows
®
2000 operating system
*
5
Microsoft
®
Windows
®
XP operating system *
6
Microsoft
®
Windows Server
®
2003 operating system
Printing Speed: DP-8060: Up to 60 sheets/minute
DP-8045: Up to 45 sheets/minute
DP-8035: Up to 35 sheets/minute
Resolution (dots per inch): Max. 1200 x 600 dpi
Interface: Ethernet (10Base-T/100Base-TX)
Parallel Port
Applicable OS: Windows 98*
1
, Me*
2
, NT 4.0*
3
(with service pack 3 or later is required),
2000*
4
, XP*
5
, Server 2003*
6
Tray Capacity Letter: Maximum 85 sheets (20 lb: 75 g/m
2
)
Invoice/Legal/Ledger: Maximum 70 sheets (20 lb: 75 g/m
2
)
Paper Size Invoice/Letter/Legal/Ledger
Paper Weight 14 - 28 lb (50 - 105 g/m
2
)/1-sided
17 - 28 lb (64 - 105 g/m
2
)/2-sided
Electrical Requirements Supplied from copier
Dimensions (W x D x H) 23.6 x 23.0 x 5.9 in (600 x 583 x 151 mm)
i-ADF
*1
(Standard)
Combination Paper Tray x 1
Storage Tray x 1
Paper Size Invoice/Letter/Letter-R/Legal/Ledger
Paper Weight 16 - 24 lb (60 - 90 g/m
2
)
Paper Capacity Maximum 550 sheets x 1: 20 lb (75 g/m
2
)
Electrical Requirements Supplied from copier
Dimensions (W x D x H) 23.6 x 28.7 x 11.4 in (600 x 730 x 290 mm)
Weight 64 lb (29 kg)
Applicable Models DP-8060/8045/8035
System Console 1 (DA-DS603)
Combination Paper Tray x 2
Paper Size Invoice/Letter/Letter-R/Legal/Ledger
Paper Weight 16 - 24 lb (60 - 90 g/m
2
)
Paper Capacity Maximum 550 sheets x 2: 20 lb (75 g/m
2
)
Electrical Requirements Supplied from copier
Dimensions (W x D x H) 23.6 x 28.7 x 11.4 in (600 x 730 x 290 mm)
Weight 66 lb (30 kg)
Applicable Models DP-8060/8045/8035
System Console 2 (DA-DS604)
Specifications
*
1
inverted-ADF
