- Specifications
67
Appendix
Compatibility ITU-T Group 3
Coding Scheme JBIG, MH, MR, MMR (Conforms to ITU-T Recommendations)
Modem Type ITU-T V.34, V.17, V.29, V.27 ter and V.21
Modem Speed 2,400 - 33,600 bps
Document Size Ledger/Legal/Letter/Letter-R/Invoice/Invoice-R
Max : Platen Glass : 11" x 17" (Ledger)
ADF : 11" (Original's Width)
Min : Platen Glass : No Minimum
ADF : 5.5" x 8.5" (Invoice)
Scanning Method Sheet Feeding with CCD type image sensor
Effective Scanning Width 10.8" (274 mm)
Scanner Resolution Horizontal
Standard and Fine Resolution : 203 pels/inch (8 pels/mm)
Super Fine Resolution : 406 pels/inch (16 pels/mm)
Vertical
Standard Resolution : 98 lines/inch (3.85 lines/mm)
Fine Resolution : 196 lines/inch (7.7 lines/mm)
Super Fine Resolution : 391 lines/inch (15.4 lines/mm)
Address Book Memory 1000 stations
Capacity Each station can register up to 36 digits for each telephone number
(including pauses and spaces) and up to 15 characters for each station name
Image Memory Capacity Base Memory 3 MB : 180 pages
with 4 MB Flash Memory Card : 500 pages
with 8 MB Flash Memory Card : 820 pages
(Based on ITU-T Image No.1 using Standard Resolution)
FCC Registration Number US: BTLFA15BMGCS02-01
Ringer Equivalence 1.5 B
For G3 Facsimile (Option) [DA-FG600]
Standard Compliance 10Base-T Ethernet (IEEE 802.3), 100Base-TX Fast Ethernet (IEEE802.3u)
Connector Interfaces 10/100 Base-TX port: RJ-45
Compatibility IETF RFC 3965, ITU-T T.37
Communication Protocol TCP/IP, SMTP, POP3, MIME
File Format TIFF [IETF RFC 3949 Profile S, F, J]
PDF
Email Receiving Width Maximum LEDGER size
For Internet Fax (Email) [Standard]
