- Specifications
Appendix
68
Paper Size Letter-R/Legal
Paper Weight 20 lb (75 g/m
2
)
Paper Capacity Letter-R : Maximum 2500 sheets
Legal : Maximum 1500 sheets
Applicable Model DP-8060/8045/8035
Letter-R/Legal Size Adaptor for 3000-Sheet Tray (LCT) (DA-TK31)
2-Bin Finisher (DA-FS600)
Paper Size Letter (Letter-R/Legal with optional DA-TK31)
Paper Weight 16 - 24 lb (60 - 90 g/m
2
)
Paper Capacity Maximum 3000 sheets x 20 lb (75 g/m
2
)
Electrical Requirements Supplied from copier
Dimensions (W x D x H) 11.7 x 17.5 x 19.9 in (295 x 445 x 505 mm)
Weight 33 lb (15 kg)
Applicable Models DP-8060/8045/8035
3000-Sheet Tray (LCT) (DA-MA301)
Specifications
Mode Non-sort/Sort/Staple
Paper Size Invoice/Letter/Letter-R/Legal/Ledger
Paper Weight 16 - 35 lb (60 - 135 g/m
2
): Non-sort mode
Paper Capacity Maximum: 1000 sheets / 30 set (Stapling mode)
Staple Paper Size
Letter/Letter-R/Legal/Ledger
Paper Weight
17 - 21 lb (64 - 80 g/m
2
)
Capacity 2-50 sheets: Letter (20 lb: 75 g/m
2
)
2-30 sheets: Letter-R/Legal/Ledger (20 lb: 75 g/m
2
)
Point Rear 1/Front 1/Middle 2-Point Staple
Electrical Requirements Supplied from copier
Dimensions (W x D x H) 26.4 x 24.2 x 59.1 in (670 x 613 x 1500 mm)
Weight 70 lb (32 kg)
Applicable Models DP-8060/8045
