Digital Imaging Systems DP-8060 / 8045 / 8035 Operating Instructions

69
Appendix
Mode 1 Bin and 2 Bin Non-sort/Sort/Staple
Stitch Tray Saddle-Stitch
Paper Size 1 Bin and 2 Bin Invoice/Letter/Letter-R/Legal/Ledger
Stitch Tray Letter-R/Ledger
Paper Weight 16 - 35 lb (60 - 135 g/m
2
): Non-sort mode
Paper 1 Bin and 2 Bin Maximum: 1000 sheets / 30 set (Stapling mode)
Capacity
Stitch Tray Maximum: 30 set
Staple Paper Size Letter/Letter-R/Legal/Ledger
Paper Weight 17 - 21 lb (64 - 80 g/m
2
)
Capacity 2 - 50 sheets: Letter (20 lb: 75 g/m
2
)
2 - 30 sheets: Letter-R/Legal/Ledger (20 lb: 75 g/m
2
)
Point Rear 1/Front 1/Middle 2-Point Staple
Saddle-Stitch Paper Size Letter-R/Ledger
Paper Weight 17 - 21 lb (64 - 80 g/m
2
)
Stack 11 - 15 sheets: 10 sets/6 - 10 sheets: 15 sets/2 - 5 sheets: 25 sets
Electrical Requirements Supplied from copier
Dimensions (W x D x H) 26.4 x 24.2 x 59.1 in (670 x 613 x 1500 mm)
Weight 114 lb (52 kg)
Applicable Models DP-8060/8045
2-Bin Saddle-Stitch Finisher (DA-FS605)
Paper Size Letter/Ledger : 3-hole / Letter-R/Legal : 2-hole
Paper Weight 17 - 35 lb (64 - 133 g/m
2
)
Applicable Models DP-8060/8045
Punch Unit (DA-SP31) [for DA-FS600/605]
2-Bin Finisher (DA-FS330) (1/2)
<Continue on the next page...>
Mode 1 Bin Non-sort/Sort
2 Bin Non-sort/Shift-Sort (Letter Portrait only)/Staple (Letter Portrait only)
Paper Size 1 Bin Invoice/Letter/Letter-R/Legal/Ledger
2 Bin Letter
Paper Weight 16 - 35 lb (60 - 135 g/m
2
): Non-sort mode
Paper 1 Bin 100 sheets
Capacity
2 Bin Maximum: 1000 sheets / 30 set (Stapling mode)
Staple Paper Size Letter
Paper Weight 17 - 21 lb (64 - 80 g/m
2
)
Capacity 2 - 30 sheets: 20 lb (75 g/m
2
)
Point 1-Point Staple
