5.8 GHz Expandable Cordless Handset Operating Instructions Model No. KX-TGA523 Pulse-or-tone dialing capability The KX-TGA523 will only work with the Panasonic cordless phone systems: KX-TG5200/KX-TG5202/ KX-TG5210/KX-TG5212/ KX-TG5230/KX-TG5240/ KX-FPG391 PLEASE READ BEFORE USE AND SAVE. Charge the battery for 6 hours before initial use. 1 2 3 4 5 6 Panasonic World Wide Web address: http://www.panasonic.
1 Getting Started 1-A Accessories 1-B Location of Controls (included) Handset Battery ..............................one Order No. HHR-P104 Charger (with Clock Radio) [SNOOZE/MUTE] Button (2-D, 4-C) Ringer/Message Alert Indicator Antenna [RADIO, ALARM SET] Button (4-A) Handset Cover ..................one Order No. PQKK10142Z1 Display Belt Clip ............................one Order No. PQKE10377Z1 Charger Unit .....................one Charger Order No. KX-TGA523M AC Adaptor Order No.
Getting Started Section 1 1-F Battery Charge Place the handset on the charger and charge for 6 hours before initial use. •The unit beeps once, the CHARGE indicator lights and “Charging” is displayed. •When the battery is fully charged, “Charge completed” is displayed if there are no new calls in the Caller List. CHARGE Indicator •Recharge the battery when: – “Recharge battery” is displayed on the handset, –“ ” flashes, or – the handset beeps intermittently while it is in use.
2 Listening to the Radio Section 2 2-C Improving Reception Memory Buttons ([M1], [M2], [M3], [M4] and [M5]) [SNOOZE/MUTE] [+, -, TUNE/CLOCK] [OFF] VOLUME Control For FM For AM Extend the cord and place the antenna in a location where reception improves. Reorient the antenna horizontally until reception improves. [FM/AM, RADIO] Loud 2-D Muting the Radio Press [SNOOZE/MUTE] while listening to the radio. •“ ” flashes on the display. •To release the mute, press [SNOOZE/MUTE] again.
4 Using the Alarms Section 4 The charger unit features an alarm clock. You can set the alarm to play the radio or to sound a buzzer at a set time. The radio alarm and the buzzer alarm can be set separately. [RADIO, ALARM SET] Memory Buttons ([M1], [M2], [M3], [M4] and [M5]) 4-B Setting the Buzzer Alarm 1 Press [BUZZER, ALARM SET]. • If you do not proceed to the next step within 5 seconds, the display will return to the current time.
5 Things You Should Know 5-A Optional Headset 5-C FCC and Other Information Connecting an optional headset to the handset allows hands-free phone conversation. Please use only a Panasonic KX-TCA60, KX-TCA86, KX-TCA88, KX-TCA88HA, KX-TCA91, KX-TCA92 or KX-TCA98 headset. To order, call the accessories telephone number in section 1-A. To connect a headset Open the headset jack cover, and insert the headset plug into the headset jack as shown. Headset Jack H Headset sold separately.
Section 5 6 Referencia rápida 6-A Preparación 4. Exercise care in handling batteries in order not to short the battery to conductive materials such as rings, bracelets, and keys. The battery and/or conductor may overheat and cause burns. 5. Charge the battery(ies) provided with or identified for use with this product only in accordance with the instructions and limitations specified in this manual.
Referencia rápida 6-B Para escuchar la radio Para registrar la unidad portátil Sintonizacíon manual Esta unidad portátil deberá ser registrada en la unidad base KX-TG5200/KX-TG5202/KX-TG5210/KX-TG5212/KX-TG5230/ KX-TG5240/KX-FPG391. A la unidad portátil se le asignará su número de extensión al registrarla. [FM/AM, RADIO] para encender 1 Presione la radio. [FM/AM, RADIO] para cambiar 2 Presione de FM a AM y viceversa. [-] Press LOCATOR on base unit for 3 sec.
Sección 6 6-C Configuración del temporizador para dormir Con la radio encendida, presione [SLEEP] repetidamente para seleccionar la hora (minutos). •Con cada presión de [SLEEP] la hora cambia como sigue: 30 60 90 120 OFF Ej.: Tiempo de temporizador para dormir: 30 min. •La radio se apagará automáticamente después de que transcurra el tiempo de temporizador para dormir seleccionado. 6-D Uso de las alarmas Para configurar la alarma de radio 1 Presione [RADIO, ALARM SET].
Attach your purchase receipt here. For product service • Visit our website: http://www.panasonic.com/support • Contact us via the web at: http://www.panasonic.com/contactinfo • Call us at: 1-800-211-PANA(7262) When you ship the product • Carefully pack your unit, preferably in the original carton. • Attach a letter, detailing the symptom, to the outside of the carton. Symptom • Send the unit to an authorized servicenter, prepaid and adequately insured.
