Digital Camera User Manual

Before Use
- 14 -
About the Lens
∫ Micro Four Thirds™ mount specification lens
This unit can use the dedicated lenses compatible with
the Micro Four Thirds System lens mount specification
(Micro Four Thirds mount).
∫ Four Thirds™ mount specification lens
Lens with the Four Thirds mount specification can be
used by using the mount adaptor (DMW-MA1; optional).
∫ Leica mount specification lens
•
When you use the M mount adaptor or R mount adaptor (DMW-MA2M, DMW-MA3R;
optional), you can use Leica M Mount or Leica R Mount interchangeable lenses.
– For certain lenses, the actual distance at which the subject is in focus may differ slightly from
the rated distance.
– When using a Leica lens mount adaptor, set [SHOOT W/O LENS] (P143) to [ON].
There are functions that cannot be used, or the operation may be different depending on
the lens used.
Auto Focus
¢
/Auto aperture setting
¢
/the Direction Detection Function (P32)/
[DEFOCUS CTRL] (P42)/[STABILIZER] (P69)/[QUICK AF] (P127)/[SHADING COMP.]
(P131)
¢ Interchangeable lenses (H-FS014042, H-FS045200) are compatible with the Auto Focus
and automatic Aperture operation during the recording of motion pictures. With the optional
HD motion picture compatible interchangeable lens (H-VS014140), a more smooth and quiet
motion picture recording is possible with high AF following performance and silence design.
For details on the lens used, refer to the website.
Note
•
The available flash range etc. differs depending on the aperture value of the lens you are using.
• The focal length noted on the lens in use is equivalent to double when converted to the 35 mm
film camera. (It will be equivalent to 100 mm lens when a 50 mm lens is used.)
Refer to the website for details about the 3D interchangeable lens.
About the lens and functions
Refer to catalogues/Web pages for most current information regarding compatible
lenses.
http://panasonic.jp/support/global/cs/dsc/
(This Site is English only.)
