Operation and Maintenance
6-13
9783-A2-GB20-00
July 2000
System and Test Status Messages
System and test status information is selected from the Status menu.
Main Menu
→
Status
→
System and Test Status
The following information is included on this screen:
H
Self-Test Results Messages
H
Last System Reset Date and Time
H
Health and Status Messages
H
Test Status Messages
Self-Test Results Messages
One of these self-test result messages appear in the Self-Test Results field at the
top of the System and Test Status screen.
Table 6-6. Self-Test Results Messages
Message
What It Indicates What To Do
Failure
xxxxxxxx
An internal failure occurred
(xxxxxxxx
represents an
8-digit hexadecimal failure
code used by service
personnel).
Record the failure code
before resetting the unit;
otherwise, the error
information will be lost.
1. Record the failure code.
2. Reset the unit.
3. Contact your service
representative.
Passed No problems were found
during power-on or reset.
No action needed.
Last System Reset Date and Time
This field indicates the last time the FrameSaver unit was reset. It appears after
the Self-Test Results field at the top of the System and Test Status screen.
H Date is in mm/dd/yyyy format (month/day/year).
H Time is in mm:ss format (minutes:seconds).
