9-1
9783-A2-GB20-00
July 2000
Setting Up OpenLane for
FrameSaver Devices
9
This chapter includes:
H
OpenLane Support of FrameSaver Devices
H
Setting Up the OpenLane SLM System
H
Setting Up FrameSaver and SLV Support
OpenLane Support of FrameSaver Devices
The OpenLane Service Level Management (SLM) system provides the following
features:
H Web and database services
H Web access to health and status information
H Web access to real-time, as well as historical graphs and reports
H Web access to SLV reports, for units with the SLV feature set activated.
H On-demand polling of FrameSaver devices
H SNMP polling and reporting
H Web-based diagnostic tests: end-to-end, PVC loopbacks, connectivity, and
physical interface tests
H Basic device configuration, including RMON alarm and threshold
configuration when the unit has the advanced SLV feature set activated
H Automatic device and PVC discovery for SLV devices with their SLV Delivery
Ratio configuration option enabled
H Easy firmware downloads to an entire network or parts of the network
H Remote SLV feature activation
