209M 1104 Oxygen Combustion Vessel Operating Instruction Manual
1104 Oxygen Combustion Vessel Table of Contents Preface Scope — 3 Related Instructions — 3 Purpose — 3 Description — 3 Accessories and Utilities — 3 Parts List —8 Drawings 1104 Oxygen Combustion Vessel — 9 1104 Oxygen Combustion Vessel - Head Assembly — 10 Oxygen Filling Connection for the 1104 Oxygen Combustion Vessel — 11 Sample Preparation —3 Operation Setting the Calorimeter Parameters — 4 Preparing the Fuse When the Combustion Cage is Used — 5 Preparing the Fuse When the Combustion Cage is Not Used —
1104 Oxygen Combustion Vessel Preface Scope These instructions cover the procedures to be followed when using a Parr 1104 Oxygen Combustion Vessel (or bomb) to determine calorific values of solid or liquid combustible material in a Parr calorimeter. The user should study these instructions carefully in order to obtain a complete understanding of the capabilities and limitations of an 1104 Oxygen Combustion Vessel, and to be well aware of the precautions to be observed in its operation.
1104 Oxygen Combustion Vessel Sample Preparation (continued) Operation It is not advisable to test true explosives in the presence of oxygen. Some of the end products of the explosion will be combustible in high-pressure oxygen, for example, mixed oxides of nitrogen and carbon monoxide. With high-pressure oxygen available, these will burn to carbon dioxide and release an undeterminable amount of heat that did not come from the initial reaction of interest.
1104 Oxygen Combustion Vessel Preparing the Fuse When the Combustion Cage is Used Set the bomb head on the support stand (P/N A38A) and attach one end of a 10 cm length of fuse wire to the hook on the straight electrode. Run the wire through the slot in the cage, then up through one of the holes in the top plate. Anchor the free end under the head of one of the nearby screws.
1104 Oxygen Combustion Vessel Preparing the Fuse When the Combustion Cage is Not Used (Continued) Set the bomb head on the support stand (P/N A38A) and attach one end of a 10 cm length of fuse wire between the two electrodes. Fasten one end of the wire to the loop electrode (steps a thru d) then attach the other end to the straight electrode (steps e thru h). Pull the loop downward to tighten the connections then bend the wire upward (step i).
1104 Oxygen Combustion Vessel threaded on instead of pushed on to the inlet valve. The correct assembly to use when filling the 1104 from a calorimeter is P/N A19A15. Close the outlet valve on the bomb head. Thread the end of the fill connection on to the inlet valve of the 1104. Press “O2 Fill” on the calorimeter to fill the vessel. Filling the Bomb Manually To fill the vessel directly the 1823 Oxygen Fill Connection must be used. Close the outlet valve on the bomb head.
1104 Oxygen Combustion Vessel Parts List Part No. A206A5 A208A A207A 212A2 A206A6 208AF 1104 Oxygen Combustion Vessel Description Head Assembly w/ Cage Screw Cap Cylinder w/ Screw Cap Compression Ring Head Assembly w/ Loop Cap Screws Part No.
1104 Oxygen Combustion Vessel Drawings 1104 Oxygen Combustion Vessel 212A2 REF COMPRESSION RING A206A5 HEAD ASSEMBLY A208A SCREW CAP REF 207A CYLINDER REF: 4080LK DO NOT SCALE DRAWING PROPRIETARY NEITHER THE DRAWING NOR INFORMATION CONTAINED HEREIN MAY BE COPIED, REPRODUCED, OR REVISIONS FOR 1104 OXYGEN BOMB IN INCHES UNLESS OTHERWISE SPECIFIED R1 ADDED REF, WAS IDM; [EC11321] TOLERANCES 1/X .... ±1/64 .00 .... ±.010 .000 .... ±.003 ANGULAR ... ±1/2° PARR INSTRUMENT CO.
1104 Oxygen Combustion Vessel 1104 Oxygen Combustion Vessel - Head Assembly 10 Parr Instrument Company
04 Oxygen Combustion Vessel Oxygen Filling Connection for the 1104 Oxygen Combustion Vessel www.parrinst.
Revision 04/04/13
