SmartNode 4950-NCE overview 15
SmartNode 4950-NCE Getting Started Guide 1 • General information
SN4950-NCE model codes
The SmartNode 4950-NCE series consists of several models. They differ in the number of PRI ports and voice
channels supported. All models come equipped with two 10/100/1000Base-T Ethernet ports. The SmartNode
4950-NCE PRI ports and voice channels are listed in table 2. The SmartNode 4950-NCE G.SHDSL models
are listed in table 3.
Table 2. SmartNode 4950-NCE PRI Ports and Voice Channels
Model PRI Ports Voice Channels
SN4950-
NCE/1E24V/EUI
1 24
SN4950-
NCE/1E30V/EUI
1 30
SN4950-
NCE/4E24V/EUI
4 24
SN4950-
NCE/4E30V/EUI
4 30
SN4950-
NCE/4E48V/EUI
4 48
SN4950-
NCE/4E60V/EUI
4 60
SN4950-
NCE/4E96V/EUI
4 96
SN4950-
NCE/4E120V/EUI
4 120
Table 3. SmartNode 4950-NCE models with integrated G.SHDSL interface
Model PRI Ports Voice Channels
SN4950-
NCE/1E24V2GS/EUI
1 24
SN4950-
NCE/1E30V2GS/EUI
1 30
SN4950-
NCE/4E24V2GS/EUI
4 24
SN4950-
NCE/4E30V2GS/EUI
4 30
SN4950-
NCE/4E48V2GS/EUI
4 48
SN4950-
NCE/4E60V2GS/EUI
4 60
SN4950-
NCE/4E96V2GS/EUI
4 96
SN4950-
NCE/4E120V2GS/EUI
4 120
