Identification of the SmartNode devices via SNMP 52
SmartNode 4950-NCE Getting Started Guide B • Specifications
Note
The SysObjectIDs for the SN4950-NCE G.SHDSL models are the same as
the corresponding non-G.SHDSL models listed above.
According to table 13, an SNMP get request to .iso.org.dod.internet.mgmt.mib-2.system.sysObjectID of a Smart-
Node 4950/1E30V2GS/EUI-NCE device reads out a numeric OID of 1.3.6.1.4.1.1768.100.4.15.1. The
mapping of the sysObjectID to each of the SmartNode model is realized with the SmartNode product identifi-
cation MIB.
SN4951/4E96V .iso.org.dod.internet.private.enterprises.patton.products.sn49xx.19
1.3.6.1.4.1.1768.100.4.15.19
SN4951/4E120V .iso.org.dod.internet.private.enterprises.patton.products.sn49xx.20
1.3.6.1.4.1.1768.100.4.15.20
The SNMP agent running in SmartWare is SNMP version 1
(SNMPv1) compliant. SNMP version 2 (SNMPv2) and SNMP
version 3 (SNMPv3) are not currently supported.
Table 13. SmartNode Models and their Unique sysObjectID (Continued)
SmartNode Model SysObjectID
IMPORTAN
T
