Identification of the SmartNode devices via SNMP 45
SmartNode 4940 Getting Started Guide B • Specifications
Identification of the SmartNode devices via SNMP
All SmartNode devices have assigned sysObjectID (.iso.org.dod.internet.mgmt.mib-2.system.sysObjectID)
numbers (see table 7).
Table 7. SmartNode Models and their Unique sysObjectID
SmartNode Model SysObjectID
SN4940/1E15V .iso.org.dod.internet.private.enterprises.patton.products.sn49xx.1
1.3.6.1.4.1.1768.100.4.16.1
SN4940/1E24V .iso.org.dod.internet.private.enterprises.patton.products.sn49xx.2
1.3.6.1.4.1.1768.100.4.16.2
SN4940/1E30V .iso.org.dod.internet.private.enterprises.patton.products.sn49xx.3
1.3.6.1.4.1.1768.100.4.16.3
SN4940/4E15V .iso.org.dod.internet.private.enterprises.patton.products.sn49xx.4
1.3.6.1.4.1.1768.100.4.16.4
SN4940/4E24V .iso.org.dod.internet.private.enterprises.patton.products.sn49xx.5
1.3.6.1.4.1.1768.100.4.16.5
SN4940/4E30V .iso.org.dod.internet.private.enterprises.patton.products.sn49xx.6
1.3.6.1.4.1.1768.100.4.16.6
SN4940/4E48V .iso.org.dod.internet.private.enterprises.patton.products.sn49xx.7
1.3.6.1.4.1.1768.100.4.16.7
SN4940/4E60V .iso.org.dod.internet.private.enterprises.patton.products.sn49xx.8
1.3.6.1.4.1.1768.100.4.16.8
SN4940/4E96V .iso.org.dod.internet.private.enterprises.patton.products.sn49xx.9
1.3.6.1.4.1.1768.100.4.16.9
SN4940/4E120V .iso.org.dod.internet.private.enterprises.patton.products.sn49xx.10
1.3.6.1.4.1.1768.100.4.16.10
SN4951/1E15V .iso.org.dod.internet.private.enterprises.patton.products.sn49xx.11
1.3.6.1.4.1.1768.100.4.16.11
SN4951/1E24V .iso.org.dod.internet.private.enterprises.patton.products.sn49xx.12
1.3.6.1.4.1.1768.100.4.16.12
SN4951/1E30V .iso.org.dod.internet.private.enterprises.patton.products.sn49xx.13
1.3.6.1.4.1.1768.100.4.16.13
SN4951/4E15V .iso.org.dod.internet.private.enterprises.patton.products.sn49xx.14
1.3.6.1.4.1.1768.100.4.16.14
SN4951/4E24V .iso.org.dod.internet.private.enterprises.patton.products.sn49xx.15
1.3.6.1.4.1.1768.100.4.16.15
SN4951/4E30V .iso.org.dod.internet.private.enterprises.patton.products.sn49xx.16
1.3.6.1.4.1.1768.100.4.16.16
SN4951/4E48V .iso.org.dod.internet.private.enterprises.patton.products.sn49xx.17
1.3.6.1.4.1.1768.100.4.16.17
SN4951/4E60V .iso.org.dod.internet.private.enterprises.patton.products.sn49xx.18
1.3.6.1.4.1.1768.100.4.16.18
SN4951/4E96V .iso.org.dod.internet.private.enterprises.patton.products.sn49xx.19
1.3.6.1.4.1.1768.100.4.16.19
