Products Current Clamp Adapters 4mm / BNC PeakTech® 4300
PeakTech
®
4300 PROD-ID: P 4300
Current Clamp Adapter for Multimeter ~ 1000 A AC/DC ~
with 4mm Plugs
This clampadaptor is transducer, which will allow your multimeter to
measure electrical current up to 1000 A AC/DC with a frequency
response up to 400 Hz. When measuring current with this clampadaptor,
there is no need to break a circuit or to affect the insulation. This
adaptor with a design of finger guard, which ensures user operating the
clamps under a safe situation. For conductor diameter up to 57 mm, an
output of 1 mV/A (1000:1) and an input impedance of 1 MΩ.
Safety: EN 61010-1, CAT II 1000 V
Accessories: Battery and manual
DCA 200/1000 A; ± 1,5% + 2 A - 1 mV/A
ACA 200/1000 A; ± 1,5% + 2 A - 1 mV/A
Operation voltage 9V-Battery
Dimensions (WxHxD) 100 x 240 x 43 mm
Weight 515 g
EAN-13 4250569401138
