LL27LM

Mounting Bracket

Installation/Operation

C206M (6/93)

Pelco • 3500 Pelco Way, Clovis, CA 93612-5699 • USA • (800) 289-9100 or (1-559) 292-1981

FAX (800) 289-9150 or (1-559) 292-3827

International Customers call (1-559) 292-1981 or FAX (1-559) 348-1120

1.0 WARNINGS

Prior to installation and use of this product, the follow-

ing WARNINGS should be observed.

1. Installation and servicing should only be done by

Qualified Service Personnel and conform to all

Local codes.

2. Use only installation methods and materials ca-

pable of supporting four times the maximum speci-

fied load.

3. Only use replacement parts recommended by Pelco.

Please thoroughly familiarize yourself with the informa-

tion in this manual prior to installation and operation.

2.0 DESCRIPTION

The LL27LM mounting bracket is designed to allow you

to mount an LL27 infrared illuminator to any Legacy

Series enclosure. Only one infrared illuminator can be

mounted to the enclosure/pan and tilt assembly.

3.0 INSTALLATION

3.1 INSTALLING THE LL27LM

BRACKET

3.1.1 EH4700L/EH5700L Series

Enclosures

To install the LL27LM bracket perform the following

steps. (Refer to Figure 3.)

1. Remove enclosure from pan/tilt, if necessary.

2. Loosen the two 1/4-20 bolts (item K) from the tilt

table (item 3) on the bottom of the enclosure.

3. Remove cradle (item 4) and replace with LL27LM

mounting bracket.

The long arm of the LL27 bracket should be posi-

tioned over the tilt gear side of the pan/tilt unit.

4. Re-attach the tile table (item 3) using the two 1/4-

20 bolts previously removed.

LISTED

Summary of content (4 pages)

PAGE 1
® LL27LM Mounting Bracket Installation/Operation UL ® C206M (6/93) LISTED 1.0 WARNINGS 3.0 INSTALLATION Prior to installation and use of this product, the following WARNINGS should be observed. 3.1 INSTALLING THE LL27LM BRACKET 1. Installation and servicing should only be done by Qualified Service Personnel and conform to all Local codes. 3.1.1 EH4700L/EH5700L Series Enclosures 2. Use only installation methods and materials capable of supporting four times the maximum specified load.
PAGE 2
3.1.2 EH8106L Enclosure 3.2 ATTACHING THE LL27 INFRARED ILLUMINATOR Refer to Figure 4 for the following instructions. 1. Remove the two screws in the tilt table (item 1) on the EH8106L enclosure. 2. Pry the tilt table apart from the adapter plate (item 2). The two parts are held together with silicone sealant. 3. Clean the silicone from the mating surfaces of the adapter plate and tilt table. 4. Apply new silicone to the mating surfaces. 5.
PAGE 3
Item 3 Item 4 Item K Tilt table Cradle Bolt, 1/4-20 x 5/8 Phillips flat M/S SS Figure 3. Legacy® Series Enclosure Exploded Assembly Diagram 2 3 1 Figure 4.
PAGE 4
.0 WARRANTY AND RETURN INFORMATION WARRANTY Pelco will repair or replace, without charge, any merchandise proved defective in material or workmanship for a period of one year after the date of shipment. Exceptions to this warranty are as noted below: • Five years on FT/FR8000 Series fiber optic products. • Three years on Genex® Series products (multiplexers, server, and keyboard).
