I N S T A L L A T I O N CM1750/CM1750-BK/ CM1750-PVM/CM1750S/ CM1750S-BK/BS1750/ TB1750 Camera Mount C218M-C (11/05)
Important Safety Instructions 1. Installation and servicing should be done only by qualified service personnel and conform to all local codes. 2. Installation shall be done in accordance with all local and national electrical and mechanical codes utilizing only approved materials. 3. Use only installation methods and materials capable of supporting four times the maximum specified load.
Specifications Pan Adjustment Tilt Adjustment Construction Finish Locking Method Camera Mounting Maximum Load Dimensions Weight BS1750 CM1750-PVM CM1750/-BK CM1750S/-BK CM1750EXT/-BK TB1750 360° 90° Aluminum Gray polyester powder coat with black swivel assembly (except for the CM1750-BK, CM1750S-BK, and CM1750EXT-BK, which are all black) Set screw secures swivel assembly 1/4-20 threaded stud and nut 7 lb (3.18 kg) See Figure 1 0.25 lb (0.11 kg) 0.25 lb (0.11 kg) 0.50 lb (0.22 kg) 0.30 lb (0.14 kg) 0.
PRODUCT WARRANTY AND RETURN INFORMATION WARRANTY Pelco will repair or replace, without charge, any merchandise proved defective in material or workmanship for a period of one year after the date of shipment. Exceptions to this warranty are as noted below: • Five years on FT/FR8000 Series fiber optic products. • Three years on Genex ® Series products (multiplexers, server, and keyboard).
