Perle Protocol Transparent Media Converter Modules Installation Guide C-4GPT-DSFP CM-4GPT-DSFP Part# 5500335-10
Overview This document contains instructions necessary for the installation and operation of the Perle Protocol Transparent Media Converter modules. These Media Converter modules allow connection and cross-connection of fiber networks of different types to each other. They are protocol independent using standard SFP* modules with speeds up to 4.25 Gbps. These modules can be ordered as unmanaged modules (C) or as managed modules (CM). Both models are used in conjunction with a Perle management card.
Installation The default switch settings (all switches in the UP position) will work for most installations. See the Operation section of this guide for more details. The module comes equipped with a bank of DIP switches and a set of jumpers for setting configuration. The following steps are used to configure the Media Converter module. 1. Set the Auto-Config jumper. (CM models only) (optional). 2. Set the DIP switch settings (optional). 3. Insert SFP modules into the transceiver ports. 4.
Auto-Config Jumper (CM only) Cover the top Pin and middle Pin for Auto mode (default).
DIP Switch Settings Link Mode (Switch 1) Switch Position Mode Up (default) Smart Link Pass-Through Mode Down Standard Mode Smart Link Pass-Through: In this mode, the fiber link state on one fiber connection is directly reflected through the Media Converter module to the other fiber connection. Since this media converter module is protocol independent, it monitors the Signal Detect indicator from the SFP and reflects this on the TX port of the other SFP by turning off the transmitter.
Fiber Fault Alert (Switch 2) Switch Position Mode Up (default) Enabled Down Disabled Enabled: If the media converter module detects a loss of fiber signal on its fiber receiver, it will disable its fiber transmitter on the same SFP. This, in effect, notifies the fiber link partner that an error condition exists on the fiber connection. Disabled: The Protocol Transparent Media Converter module will not monitor for Fiber Fault.
Installing Protocol Transparent Media Converter Modules Caution: Observe electrostatic discharge precautions when installing the Protocol Transparent Media Converter module(s) into the chassis. Failure to observe this caution could result in damage to the module(s) and/or chassis. The Protocol Transparent Media Converter module(s) can be installed in any available slot and in any order within the MCR1900 chassis. 1. Remove the module from its packaging. 2.
Removing Media Convert Modules 1. Loosen the captive retainer screw on the front of the Protocol Transparent Media Converter Module and gently pull the module out. 2. If not inserting a replacement Protocol Transparent Media Converter Module then cover the opening slot with a face plate and secure the screw.
Operation Status LED The Media Converter modules have three status LEDs located on the face plate of the module. PWR On – Power On Blinking Fast – Hardware Error LK1 On – Signal Detected Off – No Signal Detected LK2 On – Signal Detected Off – No Signal Detected Troubleshooting General • • • Ensure the module is securely seated in the chassis. The PWR LED on the module should be On solid. Ensure all cabling is of the correct type and is in good operating condition.
Technical Specifications Max Power Input Consumption 3.85 Watts Ratings 6-30 VDC, 0.625A Operating Temperature 0°C - 50°C (32°F - 122°F) Storage Temperature -25°C - 70°C (-13°F - 158°F) Operating Humidity 5% to 90% non-condensing Storage Humidity 5% to 95% non-condensing Operating Altitude Up to 3,048 m (10,000 ft) Note: all combinations of modules within the MCR1900 chassis cannot exceed the chassis power input consumption.
Compliance Information EMI/EMC EN 55022/CISPR22 EN 55022/CISPR22 FCC This product has been found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
