PERLICK CR24 COLUMN REFRIGERATION PLANNING GUIDE
A L L T H E D E L I C I O U S D E TA I L S O F T H E N E W P E R L I C K C R 2 4 CO LU M N R E F R I G E R AT I O N Enjoy the flexibility of Perlick column refrigeration by mixing and matching units to create custom storage for food, wine and beverages. Columns can be installed individually or installed side-by-side in a pair or more to serve any sized kitchen. The following provides installation guidance for planning your space.
CR24D COLUMN DUAL-ZONE WINE RESERVE CR24W COLUMN SINGLE-ZONE WINE RESERVE CR24F COLUMN FREEZER CR24R COLUMN REFRIGERATOR C R 2 4 R CO LU M N R E F R I G E R ATO R C R 2 4 F CO LU M N F R E E Z E R CR24R-1-2L All Refrigerator, Solid Overlay Door, Hinged Left CR24F-1-2L All Freezer, Solid Overlay Door, Hinged Left CR24R-1-2R All Refrigerator, Solid Overlay Door, Hinged Right CR24F-1-2R All Freezer, Solid Overlay Door, Hinged Right C R 2 4 W CO L U M N W I N E R E S E RV E , C R 2 4 D CO LU M N
D O O R OV E R L AY PA N E L S Perlick CR24 column refrigeration comes ready to accept a customer-supplied door overlay panel and customer-supplied handle. A minimum 5/8" thick panel is required, however, the thickness can increase provided the panel does not exceed a weight of 65 lbs. The depth of each model is 24" without a finished overlay, so be sure to allow for panel thickness when planning the finished opening depth. This guide includes solid and glass door templates with 4" and 6" toe kicks.
G L A S S D O O R OV E R L AY T E M P L AT E G L A S S D O O R OV E R L AY T E M P L AT E F O R 4 " TO E K I C K F O R 6 " TO E K I C K Measurements shown in inches (") Measurements shown in inches (") 16-1/8" 2-1/4" 1-3/4" 14-3/8" 9-3/8" Ø 1/8" 1/2" (4X) 7-5/8" Ø 1/8" 16-1/8" 2-1/4" 3/4" 1-3/4" 7-5/8" 3/4" 6-5/8" 6-5/8" 12-1/2" 12-1/2" A B 3/8" 3/8" 36-1/2" Ø 1/8" 1/2" (12X) 36-1/2" 60-1/2" 79-7/8" 1/2" (4X) 14-3/8" 9-3/8" Ø 1/8" (12X) 1/2" 60-1/2" 60" CUTOUT 3/8" 77-
I N S TA L L I N G P E R L I C K C O L U M N R E F R I G E R AT I O N Designed specifically to be integrated into cabinetry, Perlick column refrigeration brings commercial-grade performance and preservation to any style of kitchen. Columns can be installed separately, or in side-by-side installations to create custom modular refrigeration. The following diagrams show various ways to install Perlick column refrigeration and provide information on producing custom overlay panels.
OPENING DIMENSIONS FOR A SINGLE UNIT Perlick columns allow you the freedom to install refrigeration 24-3/4" OVERALL 24" TO FRONT OF DOOR FRAME separately anywhere in the kitchen. Columns are designed to be integrated into cabinetry, however, 23-3/4" OVERALL factory installed stainless steel side 3/4" OVERLAY 25" panels are available for installations where the side of the column is exposed.
O P E N I N G D I M E N S I O N S F O R I N S TA L L I N G T H R E E U N I T S S I D E - BY- S I D E As with dual installations, choose your desired column configuration below and match to the opening (blue label) drawing for the proper cutout dimensions (applies to units installed both with or without dual installation kit.
