Specification Sheet

PERLICK CORPORATION 8300 W. Good Hope Rd., Milwaukee, WI 53223 • [phone] • perlick.com
PRODUCT SPECIFICATION SHEETS  Residential  Undercounter Refrigeration
24” ADACOMPLIANT SERIES
Beverage Center
ACCESSORIES
MODEL NOS. DESCRIPTION
L Factory Installed Lock
67164 6” Toe Kick Kit (includes riser) for HA24 models
66736 Caster Kit for HP24/HC24/HA24 models
RS2424D Divider Shelf for HP24/HC24/HA24 models
MODEL NUMBERS HA24BB
MODEL DESCRIPTION Indoor Beverage Center
ATTRIBUTES
Perlick Anti-Condensation System NO
Energy Star Certied YES
OVERALL DIMENSIONS
Width - in. (mm) 23-7/8” (606 mm)
Depth - in. (mm) 24” (610 mm)
Height - in. (mm) 32” (813 mm)
OPENING DIMENSIONS
Width - in. (mm) 24” (610 mm)
Depth - in. (mm) 24-7/8” (632 mm)
Height - in. (mm) 32-1/4” (819 mm)
INTERNAL VOLUME Net. Cu. Ft. 4.8 cu. ft total
SHIPPING WEIGHT Lbs. (kg.) 181 lbs (82.27 kg)
ELECTRICAL SPECIFICATIONS
Electrical Supply 115 VAC/60 Hz/1 Ph
Running Load Amps 2.2 amps
Electrical Connection Cord connected
Cord Plug Type
NEMA 3 Prong 5-15P
Cord Length 6’
Defrost Initiation Automatic
Defrost Type O cycle
Thermostat Digital
Lighting Type LED
REFRIGERATION SPECIFICATIONS
Refrigerant R600a (50g)
Expansion Device Capillary Tube
Temperature Settings F°C°
33° (0.5°) - 48° (8.8°)
Factory Set Point 36° (2.2°)
Heat Rejection (at 75°F) 450 BTU/hr
Pull Down Capacity 800 BTU/hr
Front Vented Yes
PLUMBING None Required
Installation Notes: To achieve 24” install depth, place electrical connection adjacent to the installation cavity.
Perlick accessories are available for purchase through an
authorized Perlick dealer. For a full list of accessories and to
nd a dealer near you, visit perlick.com.
Form No. Z2679
Rev 06.03.2021
