24” ada-compliant series

beverage center

HA24BB-3 24” INDOOR MODEL

Form No.HA24BB-3

Rev. 06.12.2015

• Available with solid stainless steel door, wood overlay door,

stainless steel glass door or wood overlay glass door

• Includes two (2) full-extension pull-out wine shelves to

accommodate eight (8) bottles each and one (1) full-

extension pull-out shelf

• Beverage Center temperature 35° - 48°F

• 32” height with leveling legs

• 525 Btu commercial-grade compressor

• Front-vented, RAPIDcool forced-air refrigeration system

• Commercial-grade stainless steel interior and black vinyl-

clad exterior

• Industry Exclusive convertible door design allows all

doors the ability to be converted to wood overlay from

stainless steel

• Industry Exclusive adjustable, full-extension pull-out

shelves

• Stainless-steel ball-bearing glides provide smooth

movement of shelves

• Low E, UV-coated glass provides industry leading

insulation and protection.

• Electromechanical temperature control

• Interior light

• Optional door locks and Industry-Exclusive drawer locks

(factory installed)

• Stacking kit available

• Also available - ADA Compliant Freezer, Refrigerator, Wine

Reserve and 15” Clear Ice Maker

• 4.8 cubic feet of capacity

• Industry Best Three Year Warranty plus additional three

years on sealed system

general 24” ADA-Compliant series

features

HA24BB-3 features

Solid Door Model

Glass Door Model

PAGE 1
24” ada-compliant series beverage center HA24BB-3 24” INDOOR MODEL C Solid Door Model US Glass Door Model general 24” ADA-Compliant series features • 32” height with leveling legs • 525 Btu commercial-grade compressor • Low E, UV-coated glass provides industry leading insulation and protection.
PAGE 2
product specifications indoor models Overall Width 23-7/8” (606 mm) HA24BB-3-1L* Solid stainless steel door, hinged left Overall Height 32” (814 mm) HA24BB-3-2L* Solid wood overlay door, hinged left Overall Depth 24” (611 mm) HA24BB-3-3L* Stainless steel glass door Opening Width 24” (611 mm) HA24BB-3-4L* Wood overlay glass door Opening Height 32-1/8” (816 mm) Opening Depth 24” (611 mm) Refrigerated Volume 4.8 cu. ft total Door Swing Clearance 25” (634 mm) Electrical 115V, 60Hz.
