Use and Care Guide

7
perlick.com
PERLICK RESIDENTIAL INSTALLATION MANUAL
Adjust the temperature as follows:
Colder Temperature:
Turn the adjusting screw clockwise (to the right).
Warmer Temperature:
Turn the adjusting screw counterclockwise (to the left).
Temperature Control OFF:
Turn the adjusting screw completely counterclockwise to the
OFF position until a click is heard.
NOTE:Thecondenserfanmotorturnsowiththecompressor.
MAINTENANCE
SEASONAL MAINTENANCE FOR ULAPPROVED OUT
DOOR MODELS
Winterizing
This process should occur when the daily low temperatures is at
or below the temperatures stated below:
Freezer models: 32° F
Refrigerator models: 38° F
Beverage Center: 42° F
Wine Reserve: 45° F
It is best to winterize your unit before the low temperatures
listed above.
1. Turn the unit to OFF position by pressing the OFF button on
the controller. The controller displays the word “OFF” and,
for Signature Series models, turn the master switch located
behind the grille o (if the power cord is accessible, unplug
the power cord. If not, turn o the circuit breaker to the
electrical receptacle the cabinet is plugged into). For C-Series
units, unplug or turn o the circuit breaker.
2. Remove all contents from the unit.
3. Remove the front grille.
4. Clean the condenser by using a vacuum cleaner to remove
loose debris (leaves, dirt, etc.) that may have accumulated
inside the grille.
5. Reinstall the front grille.
6. Clean the interior of the unit using stainless steel cleaner and
polish (see page 9).
7. Clean the exterior of the unit using stainless steel cleaner and
polish (see page 9).
NOTE:Donotplaceacoverovertheunit.Whilenotrequired,you
maychoosetoremovetheunitfromtheoutdoorlocationandstore
indoors.
Operating the unit at temperatures lower than those
recommended will void the warranty.
CAUTION
Spring Start-Up
This process should occur after the daily low temperatures is
above the temperatures stated below:
Freezer models: 32° F
Refrigerator models: 38° F
Beverage Center: 42° F
Wine Reserve: 45° F
1. Remove the grille.
2. Check the condensing unit to ensure it is clear of loose debris,
and clean as necessary with a vacuum cleaner.
3. Reattach front grille to the unit.
4. Clean the interior of the unit using stainless steel cleaner and
polish (see page 9).
5. Clean the exterior of the unit using stainless steel cleaner and
polish (see page 9).
6. Plug the unit into the electrical receptacle or turn on the
circuit breaker.
7. Turn on the master switch located behind the grille if model
is Signature Series. Press the OFF button one time to turn
the unit on. The controller display will show the actual
temperature inside the cabinet.
8. The cooling process will begin to bring the unit to the set
temperature. It’s recommended you run the unit for 24 hours
to stabilize the operating temperature before using.
DANGER
Never attempt to repair or perform maintenance on the
unit until the main electrical power to the unit has been
disconnected!
LED REPLACEMENT SIGNATURE SERIES
Call your Perlick Factory Authorized Service Center. For the
location of the Service Center in your area, contact your selling
dealer, inquire via the web at www.perlick.com, E-mail us at
[e-mail], or call
[phone] during normal business hours.
LIGHT BULB REPLACEMENT CSERIES &
ADACOMPLIANT SERIES
To replace a defective or burnt out bulb, remove the glass light
cover by pulling out on the cover, unscrew the bulb and replace
it with an identical or smaller bulb. The Perlick replacement part
number is 63716-1.
