INSTALLATION AND OPERATION INSTRUCTIONS

CUSTOM PASS-THRU BACK BAR CABINET — SELF CONTAINED AND REMOTE

Table of Contents

PREPARING THE CABINET

Specifications .....................................................2,3

List of Included Parts .............................................

Tools Required ......................................................

Plumbing ................................................................4

Electrical ................................................................

Uncrating and Inspection .......................................

Placing the Cabinet ...............................................4

Leveling the Cabinet ..............................................4

Installing Legs ......................................................

Installing the Base Plate ........................................

Electrical Condensate Evapaway Kit ....................

Refrigeration and Temperature Control .................

Cleaning the Cabinet .............................................5

Cleaning Stainless Steel .......................................5

Replacement Parts ................................................

Reversing Door Hinge ...........................................

Wiring Diagram ......................................................8
