Specification Sheet

Dimensions

Speciications

Features Code Compliance

Tenet™

Diverter Trim

016TNT1C Finish(C) q

016TNT1K Finish(K) q

016TNT1B Finish(B) q

016TNT1BG Finish(BG) q

• 0152WDX or 0154WDX Valve Required,

Order Separately

• All Metal Construction

• Optional Crosshandle Available, Order

HHL016TNT* Separately

• SecurePit™ with Anti-Handle Wobble

• Pforever Warranty®

• IAPMO Certiied

• CSA B125 Certiied

• ASME A112.18.1

• ADA Compliant-ANSI A117.1 (Lever handles only)

Pister products are designed and

manufactured in compliance with the

following standards and codes:

2-1/4

[57.2]

4-9/32

[108.6]

3-1/32

[76.7]

4-5/32

[105.3]

SS-016-TNT1X

April 5, 2019

1227209

1800PFAUCET (7328238) • pisterfaucets.com/support

REV 02

• Valve Not Included

PAGE 1
Tenet™ Diverter Trim 016-TNT1C Finish(C) q 016-TNT1K Finish(K) q 016-TNT1B Finish(B) q 016-TNT1BG Finish(BG) q Specifications • Features Valve Not Included Code Compliance • 015-2WDX or 015-4WDX Valve Required, Order Separately • All Metal Construction • Optional Crosshandle Available, Order HHL-016-TNT* Separately • SecurePfit™ with Anti-Handle Wobble • Pforever Warranty® Pfister products are designed and manufactured in compliance with the following standards and codes: • • • • IAPMO Certified CSA
