Specification

Dimensions

Speciications

Features Code Compliance

Deckard™

Single Control Roman Tub

RT61DAB Finish(B) q

RT61DAC Finish(C) q

RT61DAK Finish(K) q

• 1Hole Installation

• No Additional Valves Required

• Pforever Seal Ceramic Disc Valve

• Pforever Warranty®

Pister products are designed and

manufactured in compliance with the

following standards and codes:

1800PFAUCET (7328238) • pisterfaucets.com/support

Ø1 Min to Ø11/2 Max. Deck Hole Openings

SS-RT6-1DAX

1208000

November 10, 2017

• IAPMO Certiied

• CSA B125 Certiied

• ASME A112.18.1

• ADA Compliant-ANSI A117.1 (Lever handles only)

2-1/2

[63.2]

1-11/16

[42.9]

3 [76.2]

MAX DECK

THICKNESS

9 [228.6]

10-1/16[255.5]

8-11/16

[221]

2-25/32

[70.9]

5-11/16

[144.6]

8-3/32

[205.3]

5-5/32

[130.8]

PAGE 1
Deckard™ Single Control Roman Tub RT6-1DAB Finish(B) q RT6-1DAC Finish(C) q RT6-1DAK Finish(K) q Specifications • • • • Features Code Compliance 1-Hole Installation No Additional Valves Required Pforever Seal Ceramic Disc Valve Pforever Warranty® Pfister products are designed and manufactured in compliance with the following standards and codes: • • • • IAPMO Certified CSA B125 Certified ASME A112.18.1 ADA Compliant-ANSI A117.1 (Lever handles only) Dimensions 10-1/16[255.5] 9 [228.6] 5-5/32 [130.
