Installation Instructions

8650 College Boulevard • Overland Park, KS 66210 • www.phasetech.com • www.mseaudio.com

Phase Velocity Series

V52 · V5520 · V62 · V-Surround-II · V626

Thank you for your purchase of this Phase Velocity prod-

uct. Our mission and passion is to constantly advance

the art and science of accurate audio reproduction. We

are condent that your Phase Technology speaker will

accurately reproduce all the impact, detail and delicacy

of today’s digital technologies.

We recommend that you take the time to read this

manual thoroughly before connecting speakers to your

amplier or receiver. In the highly unlikely event that you

should experience a problem with set-up or operation,

please contact one of our carefully chosen dealers for

assistance, or contact us directly.

Phase Technology Corporation

8650 College Boulevard

Overland Park, KS 66210

(913) 663-9770 Telephone

(888) PHASE-TK Toll-Free (USA & Canada)

(913) 663-9790 Fax

CONTENTS:

Thank you 1

Table of Contents 1

Safety Instructions 2

Home Theater Speaker Placement 3

Subwoofer Application Note 3

Speaker Connections 4

Mounting Your Speaker On A Wall 5

V626 Foot Installation / Spike Installation 5

V5520 Foot Installation 6

Table Top or Shelf Placement 6

Stereo / Two Channel Operation 6

Amplier Setup and Bass Management 6

Caring for Your Phase Technology Speaker 6

Maintenance and Service 7

Troubleshooting 7

Specications 8

AN MSE AUDIO GROUP MEMBER

Summary of content (8 pages)

PAGE 1
Phase Velocity Series V52 · V5520 · V62 · V-Surround-II · V626 Installation Instructions Thank you for your purchase of this Phase Velocity product. Our mission and passion is to constantly advance the art and science of accurate audio reproduction. We are confident that your Phase Technology speaker will accurately reproduce all the impact, detail and delicacy of today’s digital technologies.
PAGE 2
SAFETY INSTRUCTIONS CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: To reduce the risk of electric shock, do not remove cover (or back). No user-serviceable parts inside. Refer servicing to qualified service personnel.
PAGE 3
HOME THEATER SPEAKER PLACEMENT Today’s digital multi-channel home theater technology has elevated the art of “surround sound” to reproduce the movie theater experience in your own home. Speaker requirements and placement are important when reproducing these multi-media effects.
PAGE 4
is placed in or near a room’s corner. If using two subwoofers, start by placing them next to the front left and right speakers, in both front corners or one in the corner and one 1/3 of the way along the front wall from the corner. Each room is different. Experiment with these options or try other locations until you get the best results. If you must choose a less-than-ideal position, the output level of Phase Technology powered subwoofers is adjustable to compensate for your listening environment.
PAGE 5
Left LCR Right LCR Center LCR Subwoofer Line Input Amplifier Panel SUB OUT Left Right Front Front Left Rear Right Rear Left Right Surr. Surr. Center Channel Left Surround Right Surround Left Rear Right Rear MOUNTING YOUR PHASE VELOCITY SPEAKER ON A WALL The V-Surround-II speaker includes a keyhole type insert for on-wall mounting. Use a #6 screw in a drywall anchor capable of holding 2-3 times the weight of the speaker in the location you wish to mount the speaker.
PAGE 6
If your floor is not rigid, the spikes may actually add to the rocking motion, so we recommend you audition the speakers with and without the spikes inserted to see if you discover a personal preference in the sound quality. Be especially careful when moving speaker cabinets with the spikes attached, as the points could damage carpeting or scratch floors. V5520 FOOT INSTALLATION Apply two of the provided adhesive bumpers to the two front corners of the speaker.
PAGE 7
MAINTENANCE AND SERVICE Because of Phase Technology’s uncompromising quality control programs, it’s unlikely that your speakers will ever need service if connected and used as outlined in this Owners’ Manual. In the unlikely event that a problem does occur, please contact your Phase Technology dealer. Your dealer has the necessary factory-authorized parts and trained technicians to quickly restore your speaker to its original performance specifications. TROUBLESHOOTING No sound 1. 2. 3.
PAGE 8
V52 V626 Tweeter 1” soft dome 1” soft dome Woofer 5.25” Vapor Deposited Titanium* 2 x 6.5” Vapor Deposited Titanium Dimensions 7.4” (W) x 10.75” (H) x 8.53” (D) 8.25” (W) x 40.5” (H) x 9.53” (D) Shipping Weight 12 lbs. 33 lbs.
