i813 – USER MANUAL
PLEASE READ BEFORE PROCEEDING THE BATTERY IS NOT CHARGED WHEN YOU TAKE IT OUT OF THE BOX. DO NOT REMOVE THE BATTERY PACK WHEN THE DEVICE IS CHARGING. YOUR WARRANTY IS INVALIDATED IF YOU DISASSEMBLE OR CHANGE THE DEVICE SHELL. INTELLECTUAL PROPERTY RIGHT INFORMATION All company, product and service names mentioned herein are trademarks, registered trademarks or service marks of their respective owners. Shanghai Feixun Communication Co., Ltd.
caused by the foregoing troubles. Some software and service may require internet support and may cause relevant cost. LIMITATION OF DAMAGES To the maximum extent permitted by applicable law, in no event shall Shanghai Feixun Communication Co., Ltd.
grounded in accordance with all local codes and ordinances. SAFETY PRECAUTIONS FOR POWER SUPPLY UNIT Use the correct power source This product can only be charged with matching battery, standard external power source or battery, external power source appointed by Shanghai Feixun Communication Co., Ltd. Shanghai Feixun Communication Co., Ltd. is not liable for any device breakdown or safety accident arising from the use of unauthorized battery or external power source by Shanghai Feixun Communication Co.
If the battery leaks: Do not allow the leaking fluid to come in contact with skin or clothing. If already in contact, flush the affected area immediately with clean water and seek medical Do advice. not allow the leaking fluid to come in contact with eyes. If already in contact, do not rub; rinse with clean water immediately and seek medical advice. Take extra precautions to keep a leaking battery away from fire as there is a danger of ignition or explosion.
areas could cause an explosion or fire resulting in bodily injury or even death. EXPLOSIVE ATMOSPHERES When in any area with a potentially explosive atmosphere or where flammable materials exist, the product should be turned off and the user should obey all signs and instructions. Sparks in such areas could cause an explosion or fire resulting in bodily injury or even death.
If you use any other personal medical device, consult the manufacturer of your device to determine if they are adequately shielded from external RF energy. Turn your phone OFF in health care facilities when any regulations posted in these areas instruct you to do so. HEARING AIDS Some digital wireless phones may interfere with some hearing aids. In the event of such interference, you may want to consult your service provider or call the customer service line to discuss alternatives.
device to prevent damaging them and causing cracked display of the touch screens. Do not put the device in your pants’ pocket for a prolonged period of time. Device getting warm after prolonged use When using your device for prolonged periods of time, such as when you’re talking on the phone, charging the battery or browsing the web, the device may become warm. In most cases, this condition is normal and therefore should not be interpreted as a problem with the device.
NOTICE: When taking the device from low-temperature conditions into a warmer environment or from high-temperature conditions into a cooler environment, allow the device to acclimate to room temperature before turning on power. Avoid pushing objects into product Never push objects of any kind into cabinet slots or other openings in the product. Slots and openings are provided for ventilation. These openings must not be blocked or covered.
distance of at least five centimeters away from pacemakers. In no case should the device be put in the front pocket of your shirt or coat. If you need detailed information about other active implantable medical devices, please consult your doctor to ensure the magnetic interference of such active implantable medical devices. ATTENTION You can only access the internet with effective data connection (3G, GPRS and EDGE) or Wi-Fi connection.
Declaration of Conformity for i813 For CE marking in the EU (European Union) Shanghai Feixun Communication Co., Ltd. Building #90, 4855 Guangfulin Rd. (HQ business park) Songjiang District Shanghai 201616 China We declare under our sole responsibility that our product Phicomm Smart Phone i813 and in combination with our accessories , to which this declaration relates is in conformity with the appropriate standards : EN 301 489-1 V1.9.2 ; EN 301 489-7 V1.3.1 ; EN 301 489-17 V2.2.1 ; EN 301 489-24 V1.5.
CONTENT I GETTING TO KNOW YOUR PHONE ................................................... 1 1.1 PHONE COMPONENTS ............................................................. 1 BOX CONTENT ............................................................................. 2 1.2 INSTALLING SIM CARD, BATTERY AND STORAGE CARD .. 2 REMOVE THE BACK COVER ..................................................... 2 PUT THE BACK COVER BACK ................................................... 3 SIM CARD........................
MOVING ITEM ON HOME SCREEN ........................................... 9 DELETING ITEMS FROM HOME SCREEN ............................... 9 CHANGING THE WALLPAPER.................................................... 9 TO ORGANIZE SYMBOLS IN FOLDERS AND TO ADD NEW SYMBOLS ...................................................................................... 9 RENAMING FOLDERS ............................................................... 10 1.8 STATUS AND NOTIFICATION .........................................
TO TURN THE SPEAKER ON OR OFF .................................... 22 TO END A CALL .......................................................................... 22 2.4 USING CALL HISTORY ............................................................. 22 TO ADD A NEW PHONE NUMBER ........................................... 22 TO CHECK MISSED CALLS ...................................................... 23 TO CLEAR CALL HISTORY LIST .............................................. 23 2.5 ADJUST CALL SETTINGS .......
SETTING A HOME PAGE ........................................................... 31 CHANGING THE SCREEN ORIENTATION .............................. 31 5.3 BLUETOOTH SETTINGS .......................................................... 31 TO TURN BLUETOOTH ON AND MAKE YOUR DEVICE VISIBLE ........................................................................................ 32 VI CAMERA AND MULTI-MEDIA ........................................................... 33 6.1 TAKING PHOTOS AND VIDEOS .................
VIII MANAGING YOUR PHONE ............................................................. 40 8.1 MANAGING BASIC SETTINGS ................................................ 40 SET DATE AND TIME ................................................................. 40 SET DISPLAY .............................................................................. 40 SET INCOMING CALL RINGTONE ........................................... 40 8.2 PROTECTING YOUR PHONE ..................................................
I GETTING TO KNOW YOUR PHONE 1.
Overhead view Buttom view BOX CONTENT The phone packaging box should contain following items and accessories: Phone Adapter Power Supply Wired Stereo Headset USB sync cable Phone battery Quick Start Guide 1.2 INSTALLING SIM STORAGE CARD CARD, BATTERY AND Make sure to always turn off the power before installing or replacing the SIM card and battery. Also, remove the back cover before you can install the SIM card, battery and storage card. REMOVE THE BACK COVER 1.
PUT THE BACK COVER BACK 1. First keep the upper half of the back cover fixed and aimit at the half opening of insertion unit. 2. Push the back cover into the fixed position from two slides and lower half part. SIM CARD The SIM card includes your phone number, the service information, the phone book and the message storage. Install SIM Card 1. Make sure the phone is off. 2. With the SIM card’s gold contacts facing down and its cut-off corner facing out, insert the SIM card into the SIM card slot.
BATTERY Your device comes with a rechargeable Lithium-ion battery and is designed to use only manufacturer-specified original batteries and accessories. Battery performance depends on many factors, including network configuration, signal strength, phone operating ambient temperature, functions and settings selected and used, items connected to the port, your sound, data and other apps usage patterns. The new battery in the phone is half charged. Please insert and charge the battery before using.
SD CARD Please install microSD card in your phone to store photos, music and apps. The camera and gallery application can only be initiated after the installation of microSD card. Install SD card Insert the microSD card into the slot with its gold contacts facing down. 1.3 CHARGING THE BATTERY 1. Plug the two ends of USB sync cable respectively into the power adapter and USB connector of your phone. 2. Plug in the power adapter to an electrical outlet to start charging the battery.
FUNCTIONS Home key: Press to get back the home screen from any application or scene Menu key:Press to start operation list for you to operate in the current scene or option. Back key: Press to get back to the former scene or close dialogue box, notification or screen keyboard. Enter the information you want in any searching box and press search again. 1.5 HOW TO USE YOUR PHONE There are various options to use your phone.
is always in a vertical direction, such as when flicking the contacts or messaging list. ROTATE For most screens you can automatically change the screen orientation from portrait to landscape by turning the phone sideways. When entering text you can turn the phone sideways to bring up a bigger keyboard. NOTICE: To automatically change the screen orientation you need to select orientation checkbox. You can find it in: Home
carrier for the PUK (PIN unblocking key) to unlock your phone. Please read chapter eight for detailed information about how to unlock SIM card. AUTOMATIC SCREEN OFF When the phone is unused for a while, the screen will be automatically closed to save power. You can still receive messages and incoming calls when it’s closed. UNLOCK SCREEN To unlock the screen press the power button. 1.7 HOME SCREEN The home screen provides a lot of free space for you to add new items.
PERSONALIZING HOME SCREEN 1. New shortcut: long press the application you want to add and drag it into the appearing “+”. 2. New folder: click on an application on the home screen and drag it to another application icon. When you drop the icon the new folder will be generated automatically. MOVING ITEM ON HOME SCREEN 1. Press and hold the items you would like to move to enable the editing mode. 2. Fix your finger on the scene and drag the item directly to the desired location and release your finger.
items from home screen” in this chapter. RENAMING FOLDERS 1. Tap the folder to open it. 2. Press and hold the title bar to activate the edit mode. 3. Insert a new name and confirm with OK. 1.8 STATUS AND NOTIFICATION STATUS ICONS The following are some of the status icons that you may see on the phone: NOTIFICATIONS Notifications icons opens to display when recieving new messages, set calendar events, clock or forwarded calls as well as your current call status.
CLOSE NOTIFICATION PANEL Press and hold the bottom of the notification panel and slide your finger upward on the screen and release. 1.9 APPLICATIONS The application screen saves all your apps other apps that has been downloaded. NOTICE: Some applcations mentioned in the user manual may not be default settings in your phone. NOTICE: To quickly open applications you can add frequently used apps to your home screen or a new folder you created.
1.10 SETTINGS You can set up the following on your phone (menu>settings): WIRELESS AND NETWORKS Alter a wireless network setting. WLAN Move the ON / OFF bar to switch on or switch of WLAN. Search: turn WLAN on and click on WLAN. You can scan for available WLAN signal. Add network: turn WLAN on and click on WLAN. Click “Add Network” to add manually a new WLAN point. Bluetooth Move the ON / OFF bar to activate or deactivate Bluetooth Click on Bluetooth to scan and search for another device.
Network settings: Manage Network settings of each subscriptions - Access Point Name: Tap the required access point to make specific parameter setting. - Network connectivity: GSM or WCDMA is optional - Network operators: select a network operator NOTICE: This device is dual SIM cards dual standby and supports two SIM cards simultaneously. Tap slot 1 or slot 2 to make separate settings of every single SIM card.
from each other.
Apps Here you can manage your applications and change the preferred installation location for new applications. PERSONAL Accounts & Sync Here you can synchronize data such as calenders and contacts with their email account. You also can add a new email account.
Credential storage: Display trusted CA certificates / Install certificates from SD card / Clear all certificates Language & Input Make the language, keyboard, speech and mouse settings.
1.11 ADJUSTING THE VOLUME Adjusting the ringer volume changes the volume level of the ringtone, while adjusting the media volume changes the volume level of sound notifications and music or video playback. Ringtone volume and media volume can be adjusted separately. You can adjust the ringer volume on the home screen or in any application dialog (except in the middle of a call or music / video playing). 1. Press the VOLUME UP or VOLUME DOWN button to adjust the ringer volume to your desired level.
Set your storage card as USB disk drive if you want to transmit music, photos and other information to your phone storage card. Set phone storage card as USB disk drive 1. Connect your phone to your computer via a USB sync cable. The following notification will appear in the panel bar ( ). 2. Open notification panel. Please double check „Opening up notification panel” in this chapter for detailed information.
II USING PHONE FEATURES 2.1 MAKING PHONE CALLS NOTICE: Most SIM cards are protected with a PIN (personal identification number) that is provided by your provider. When prompted, enter the present PIN and tap Enter. If you enter the wrong PIN three times, the SIM card will be locked. To unlock the SIM card you need the PUK (PIN unblocking key) obtained from your provider. MAKING A CALL You can dial a number directly, or use a number from your call history or contacts or call a stored contact. 1.
MAKING AN EMERGENCY CALL Enter the national emergency number (e.g. 000) and tap call. NOTICE: Additional emergency numbers may be included on your SIM card. Contact your provider for details. When you recieve a phone call from a contact, the screen will show the phone number icon, name and phone number of this contact. When you receive a phone call not existed in contacts, the screen will show the default phone number icon and the phone number itself. 2.
TO HANDLE MULTIPLE CALLS Your device notifies you when you have another incoming call, and gives you the option of rejecting or accepting the call. If you are already on a call and accept the new call, you can choose to switch between the two callers. 1. Slide the green button the right to answer the second call; first call will be put on hold. 2. To switch between the calls, tap options and choose switch. 3. After ending the call slide the red button to reject incoming calls / end incoming call.
microphone on or off. When the microphone is turned off, the mute icon will appear in the status bar. TO TURN THE SPEAKER ON OR OFF Tap Menu and then Speaker to toggle between turning the speaker on or off. WARNING!To decrease potential damage to your hearing, do not hold the phone againt your ear when the speaker is on. TO END A CALL Tap the red phone to end the call. If the caller’s phone number is not stored in your contacts, you can find in in the call history.
information, then select save. TO CHECK MISSED CALLS The missed call icon will appear in the title bar whe you missed a call. To check missed calls, press the dial button, then tap call log. NOTICE: You can press and hold the status bar, then slide down your finger on the screen to enable notification panel. The numbers of the missed calls will appear.
2.6 TO TURN THE PHONE FUNCTION ON / OFF Weny you enable the Airplane Mode, all wireless radios on your device will be turned off, including the phone function, Bluetooth and Wi-Fi. TO ENABLE / DISABLE AIRPLANE MODE 1. Tap home screen> Menu > Settings> Wireless & Network. 2. Select Airplane Mode to enable / disable the phone function. When you enable the airplane mode, the airplane mode icon will appear on the status bar.
III ENTERING TEXT 3.1 USING SCREEN KEYBOARD When you start a program or select a field that requires text or numbers, the Android Keyboard opens automatically. SELECT KEYBOARD The phone will automatically open and display keyboard when your want to enter text. 1. Tap home screen> Menu> Settings >Language & Keyboard 2. Select a language. . USIND LANDSCAPE KEYBOARD While entering text, you can rotate the device in landscape mode, and keep writing.
IV MESSAGES 4.1 SENDING SMS AND MMS You can compose and send SMS and MMS Messages to other mobile phones. OPENING MESSAGES Tap home screen and select Messages. NOTICE:The phone is dual card dual-standby, the information interface is showing all the information from both SIM cards. COMPOSING AND SENDING SMS 1. Tap Messages> Create a new message. 2. Enter the phone number or email address of the recipient in the address bar. As you type, the possible recipients from the contacts list will be displayed.
Add photo Open photo gallery and select a photo to be attached. Take a photo Open camera program and attach the taken photo. Video Opoen Video program and select a video to be attached. Recording Open the recorder. Tap start recording and then tap stop. The recording will be attached to the message. Audio Open the gallery and choose a song. Select "Yes" to send it as an attachment.Tonaufnahmen To add a slideshow Open the slideshow editor.
2. Tap a message (SMS/MMS) to pen it. 3. Select “Type Message“, enter your text and tap send. 4.3 DELETING A MESSAGE 1. Home screen> Messages 2. You can do one of the following: If you want to delete message threads, tap Menu> Delete threads and tap Delete. If you want to delete a single message, press and hold the message, then tap Delete.
Roaming auto-receive Auto-retrieve reports to know whether the message has been read or deleted without being read. Choose this option to automatically receive retrieve MMS when roaming. Choosing this option may cause an increased cost on data connection charge. Choose this option to automatically retrieve all MMS. Choosing this option can enable automatically downloading of title, content and attachment of a MMS. If you cancel it, only the title of MMS will be retrieved and displayed in message list.
V INTERNET CONNECTION Your device’s networking capabilities allow you to access the Internet through Wi-Fi, GPRS/3G or EDGE. 5.1 WI-FI Wi-Fi provides wireless Internet access over distance of up to 300 feet (100 meters). NOTICE: The availability and range of your device’s Wi-Fi signal depends on the infrastructure and other objects through which the signal passes. TO TURN ON WI-FI & CONNECT TO A WI-FI NETWORK 1. Menu> Settings> Wireless & Networks. 2. Tap Wi-Fi check box to turn it on.
available wireless network. Wi-Fi settings: Select Wi-Fi settings, then tap current wireless network your phone is connected to. 5.2 USING WEB BROWSER You can start the browser to surf the internet. NOTICE: A connection to a 3G, GPRS or Wi-Fi network is provided. OPENING THE BROWSER Tap home screen>Browser. GOING TO WEBPAGE 1. Tap the webpage address using the keyboard in the URL box. 2. As you enter the address, matching webpage address will appear on the screen.
When you turn on your device again, Bluetooth automatically turns on. Turn off Bluetooth when not in use to safe battery power, or in places where using a wireless device is prohibited. . TO TURN BLUETOOTH ON AND MAKE YOUR DEVICE VISIBLE 1. Menu> Settings 2. Wireless & Network> tap Bluetooth check box. After turning it on, the Bluetooth icon will appear in status bar.
VI CAMERA AND MULTI-MEDIA 6.1 TAKING PHOTOS AND VIDEOS You can take photos and videos using the camera. NOTICE: Make sure a storage card is installed before taking photos or videos. All photos and videos will be stored on the SD card. TO OPEN CAMERA SCREEN Tap home screen> applications > then select camera. When you open the camera, the screen orientation will automatically change as you hold the phone in different directions. NOTICE: You can easily switch your capture mode when taking photos or video.
6.2 GALLERY You can view your photos and videos in the gallery and share them or set as wallpaper or caller picture. Sie können Ihre Fotos oder Videos in der Galerie ansehen, teilen, als Hintergrundbild oder Anruferbild festlegen. Press the Menu button to get these options. OPENING GALLERY Tap home screen> applications and choose gallery. ZOOMING THE PICTURE Flicking twice on the picture can zoom in and out. You can also zoom in our out the picture using your fingers or using the zoom button.
TO OPEN MUSIC Tap home scrren, then select music and playing display will appear. TO CREATE PLAYLISTS Personalize your music experience by creating music playlists. You can make as many playlists as you like. To add a song to a playlist, press while listening to music on the menu button and select the appropriate playlist or add a new one. PLAYING SCREEN You can open the play list as following: home screen> applications > Music > Playlist Use the headset to control music player.
36
VII OTHER APPLICATIONS 7.1 USIND CALENDAR You can use the calendar for events or to enter personal appointments. ADDING EVENTS 1. 2. 3. 4. Home screen> Applications> Calendar Tap on day / time; a will appear. Enter the name of the event in the input box. You can make the following settings now: You can insert the From and To date as well as the time. Just tap on it. 5. Enter location, description and set warning. 6. When finished, tap Save. 7.
NOTICE: If you need to set more than two alarms, you can choose Add Clock to set more alarms. . DELETING THE ALARM 1. Tap applications > Clock>Set alarm. Click on the alarm you would like to delete. 2. Tap Delete. 7.3 USING SOUND RECORDER You need to install a microSD card before using sound recorder. RECORDING 1. 2. 3. 4. 5. 6. 7.4 Tap Applications> Sound Recorder Hold the microphone near your mouth. Tap to start recording. Tap to stop recording. Tap Save. Tap to play your recording.
39
VIII MANAGING YOUR PHONE 8.1 MANAGING BASIC SETTINGS SET DATE AND TIME See >>USING THE CLOCK<< in chapter seven for detailed information. SET DISPLAY Adjust screen brightness 1. Tap home screen>Menu> Settings> Display> Brightness 2. Both normal brightness and dynamic brightness are alternative; tap the right button to adjust the pattern brightness you selected. NOTICE: There are two optional ways to adjust the brightness: automatic and manual adjustment.
Setting notification ringtone 1. Tap home screen>Menu> Settings 2. Tap Sound> Default notification 3. Choose your desired notification ringtone and confirm with OK. 8.2 PROTECTING YOUR PHONE PROTECTING YOUR SIM CARD WITH A PIN You can assign a PIN to protect your SIM card from abuse. Enabling PIN for SIM card 1. Tap home screen>Menu> Settings 2. Tap Security> Set up SIM card lock 3. Enter default SIM PIN using the keypad, and confirm with OK. To change your SIM PIN select Change SIM PIN.
for spots to draw your unlock pattern, then release your fingers. NOTICE: You have to draw the pattern with your fingers instead of clicking the spots individually. 6. Your phone will record your pattern. When prompted, draw again your screen unlock pattern and tap Confirm. NOTICE: If you haven’t draw the right screen unlock pattern five times, you will be prompted to wait 30 seconds for another try. . 8.
8.4 RESETTING YOUR PHONE Resetting your phone will delete all data including downloaded apps and will return your phone to its original status. NOTICE: Backup your important data before resetting your phone. RESETTING YOUR POHNE 1. Tap home screen>Menu> Settings> Backup & reset and then tap Factory data reset. 2. On Factory data reset screen, tap reset phone. The phone will erase all data including downloaded apps etc. 8.5 TROUBLESHOOTING When using the phone, you may come into some troubles.
Make sure the correct usage of the headset. Poor call quality Make sure the internal antenna is not blocked. The phone may lose receiving function where the signal is weak. Please try another place. Have trouble with battery charging or the phone turns off when charging? Remove the phone from the charger, then reinstall and recharge the battery. Battery electrodes may be contaminated. Wipe the three gold touch points with a soft cloth and try to charge the battery again.
Can’t listen to music by remote Bluetooth headset? Make sure the phone is connected to the headset. Make sure he music format you are trying to listen to is supported by the headset. Make sure the distance between the headset and the device is beyond effective range of Bluetooth device and not blocked by walls or other obstacles.
