Schematic

ManualsBrandsPhidgets ManualsVINT PartsPhidget VINT 32 Isolated LED Controller

1

2.600"

66.040 mm

2.800"

71.131 mm

2.871"

72.912 mm

2.300"

58.420 mm

2.500"

63.512 mm

n.125"

n3.175 mm

.062"

1.580 mm

.551"

14.000 mm

LED1000_0 Mechanical Drawing
