Always there to help you Register your product and get support at www.philips.
Manufactured under license under U.S. Patent Nos: 5,956,674; 5,974,380; 6,487,535 & other U.S. and worldwide patents issued & pending. DTS, the Symbol, & DTS and the Symbol together are registered trademarks & DTS Digital Surround and the DTS logos are trademarks of DTS, Inc. Product includes software. DTS, Inc. All Rights Reserved. Manufactured under license from Dolby Laboratories. Dolby, Pro Logic, and the double-D symbol are trademarks of Dolby Laboratories.
English Contents 1 Important 2 2 3 3 3 4 4 2 Your product 4 4 5 6 7 7 Safety Care for your product Mains fuse Care of the environment Compliance Help and support Main unit Remote control Wireless speakers Wireless subwoofer Connectors 3 Connect and set up Connect the main unit Charge speakers Pair up with speakers/subwoofer Place speakers Connect to TV Connect digital devices through HDMI Connect audio from TV and other devices 8 8 8 9 9 10 11 11 4 Use your product 12 12 12 13 14 14 15 15 5 Prod
1 Important Read and understand all instructions before you use your product. If damage is caused by failure to follow instructions, the warranty does not apply. Safety Risk of electric shock or fire! • Never expose the product and accessories to rain or water. Never place liquid containers, such as vases, near the product. If liquids are spilt on or into the product, disconnect it from the power outlet immediately. Contact Consumer Care to have the product checked before use.
This is CLASS II apparatus with double insulation, and no protective earth provided. Care for your product • • • Use only microfiber cloth to clean the product, such as removing dust and shedding accumulated on the speaker cloth. Do not use any cleaning solvent to clean the wooden panels and speaker cloth. Clean the leather handles with a slightly damp soft cloth which is dipped in a leather cleaning solution, then buff the leather with a dry soft cloth.
Compliance This product complies with the radio interference requirements of the European Community. Hereby, WOOX Innovations, declares that this product is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. A copy of the EC declaration of Conformity is available at www.philips.com/support. Help and support For extensive online support, visit www.philips.
Remote control This section includes an overview of the remote control. a b NFC tag Tap the NFC-enabled device on the tag for Bluetooth connection. b (Standby-On) Switch the main unit on or to standby. c c d e English Blue LED • Lights up when you switch to Bluetooth mode and Bluetooth devices are paired. • Blinks when you switch to Bluetooth mode and Bluetooth devices are not paired. Switch to Bluetooth mode. Toggle through all sources. f +/- (Volume) Increase or decrease volume.
c Source buttons Bluetooth: Switch to Bluetooth mode; Press and hold three seconds to break the current Bluetooth connection. OPTICAL: Switch your audio source to the optical connection. COAX: Switch your audio source to the coaxial connection. AUDIO IN: Switch your audio source to the AUDIO IN connection (3.5mm jack). d SURR. SOUND ON/OFF • Turn surround sound on or off when the wireless surround speakers are docked onto the main unit.
Connectors This product comes with a wireless subwoofer. This section includes an overview of the connectors available on this product. English Wireless subwoofer On the left base speaker a b c a AC MAINS~ Connect to the power supply. b CONNECT (connect) Press to enter the pairing mode for manual connection with the main unit. c Subwoofer indicator • The white LED lights up when the subwoofer is switched on. • The white LED lights up when the subwoofer is wirelessly connected to the main unit.
On the right base speaker a b a TO L SPEAKER Connect to the left base speaker. b AC MAINS~ Connect to the power supply. 3 Connect and set up This section helps you connect this product to a TV and other devices, and then set it up. For information about the basic connections of this product and accessories, see the quick start guide. Note •• For identification and supply ratings, see the type plate at the back or bottom of the product.
2 Dock the left and right wireless speakers onto the main unit (left and right base speakers) to charge the speakers. Turn on the main unit. »» During charging, the orange LED on the wireless speaker lights up. 3 Pair up with the subwoofer 1 »» When fully charged, the orange LED on the wireless speaker turns off. Note 2 •• It may take around 3 hours to fully charge the speakers.
Dock the surround speakers You can also dock your surround speakers onto the main unit to listen to audio, for example, watching TV shows and news. SUB WOOFER L R Note •• Surround sound depends on factors such as room shape and size, type of wall and ceiling, windows and reflective surfaces, and speaker acoustics. Experiment with the speaker positions to find the optimum setting for you. Follow these general guidelines for speakers placement.
On your TV, turn on HDMI-CEC operations. For details, see the TV user manual. Note •• If your TV is not HDMI ARC compliant, connect an audio cable to hear the TV audio through the speakers of this product (see 'Connect audio from TV and other devices' on page 11). •• If your TV has a DVI connector, you can use an HDMI/ DVI adapter to connect to TV. However, some of the features may not be available.
Option 2: Connect audio through a digital coaxial cable Good quality audio 4 Use your product This section helps you use this product to play audio from connected devices. 1 Using a coaxial cable, connect the COAXIAL connector on the left base speaker of this product to the COAXIAL/ DIGITAL OUT connector on the TV or other device. • The digital coaxial connector might be labeled DIGITAL AUDIO OUT. Before you start • Make the necessary connections described in the quick start guide and the user manual.
•• If the surround speakers are undocked from the main unit, it is fixed to surround mode only. Equalizer Night mode For quiet listening, decrease the volume of loud sounds when audio is played. Night mode is only available for Dolby Digital soundtracks. 1 Change the high frequency (treble) and low frequency (bass) settings of this product. 1 2 Press TREBLE +/- or BASS +/- to change the frequency.
Play music via Bluetooth Through Bluetooth, connect your product with a Bluetooth device (such as an iPad, iPhone, iPod touch, Android phone, or laptop), and then you can listen to the audio files stored on the device through the speakers of this product. What you need • A Bluetooth device which supports Bluetooth profile A2DP, and with Bluetooth version as 2.1 + EDR. • The operational range between the main unit (left and right speakers) and a Bluetooth device is approximately 10 meters (30 feet).
Select and play audio files or music on your NFC device. • To break the connection, tap again the NFC device with the NFC tag on this product. Auto standby If no audio/video playback is detected from a connected device for 30 minutes, this product automatically switches to standby. Apply factory settings You can reset this product to the default settings programmed at the factory. 1 In OPTICAL mode, press and hold RESET for five seconds.
•• •• Dimensions (WxHxD): 160 x 300 x 160 mm Weight: 3.8 kg Surround speakers • • • • Speaker impedance: 8 ohm Speaker drivers: 2 x 63.5 mm (2.5") full range Dimensions (WxHxD): 160 x 110 x 160 mm Weight: 1.0 kg/each Subwoofer • • • • • • • Power supply: 110-240 V~, 50/60 Hz Power consumption: 30 W Standby power consumption: ≤ 0.5 W Impedance: 4 ohm Speaker drivers: 1 x 165 mm (6.5") woofer Dimensions (WxHxD): 220 x 440 x 220 mm Weight: 5.4 kg Remote control batteries • 2 x AAA-R03-1.
Distorted sound or echo. • If you play audio from the TV through this product, make sure that the TV is muted. Audio and video are not synchronized. • Press AUDIO SYNC +/- to synchronize the audio with the video. NFC A device cannot connect with this product via NFC. • Make sure that the device is supported by NFC. • Make sure that NFC is enabled on the device (see the device' s user manual for details). • For pairing, tap the NFC device on the NFC tag of this product.
Specifications are subject to change without notice 2014 © WOOX Innovations Limited. All rights reserved. Philips and the Philips’ Shield Emblem are registered trademarks of Koninklijke Philips N.V. and are used by WOOX Innovations Limited under license from Koninklijke Philips N.V. CSS7235Y_12_UM_V4.
