PLL2410W LED LCD Monitor USER'S GUIDE www.planar.
Content Operation Instructions...................................................................................................................................................1 Safety Precautions ...........................................................................................................................................................2 First Setup..................................................................................................................................................
Operation Instructions Thank you for purchasing this LED LCD Monitor, a high-resolution multi-scan color LED LCD Monitor. Please read this guide thoroughly before installation. FCC RADIO FREQUENCY INTERFERENCE STATEMENT WARNING: (FOR FCC CERTIFIED MODELS) This LED LCD Monitor has been tested and found compliant with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide proper protection against harmful interference to a residential installation.
Safety Precautions This LED LCD Monitor is manufactured and tested on a ground principle that a user’s safety comes first. However, improper use or installation may result danger to the LED LCD Monitor as well as to the user. Carefully go over the following WARNINGS before installation and keep this guide handy. WARNINGS: This LED LCD Monitor should be operated only at the correct power sources indicated on the label on the rear end of the LED LCD Monitor.
First Setup Congratulations on your purchase of this high performance LED LCD Monitor. This LED LCD Monitor comes with the following accessories : LED LCD Monitor Power Cable User’s Guide VGA Cable Base Installing the Stand Base 1. Place the monitor face down on a soft cloth or cushion on a table. 2. Install the stand base to the monitor. Disconnecting the Stand Base 1. Place the monitor face down on a soft cloth or cushion on a table. 2.
Front View of the Product OSD Menu On/Off Contrast/Brightness /Scroll Down/Adjust Decrease Preset Mode/Scroll Up/ Adjust Increase Confirm Select /Input select/Auto adjust Power ON/OFF/ LED Indicator 4
Rear View of the Product Power input (AC input) DVI Input (DVI 24 pin) VGA input (D-Sub 15 pin) 5
Quick Installation 1. Connect either VGA or DVI Video Source from the monitor to the computer. Make sure both monitor and computer are powered OFF. 2. Connect the power cord to a properly grounded AC outlet, then to the monitor. 3. Power-ON computer and then POWER-ON the monitor. 4. Set the timing mode on your computer. Recommended resolution and refresh rate is 1920 x1080 @ 60Hz.
Basic Operation Before using the LED LCD Monitor: Connect external equipments properly. Insert the power plug, and the power LED indicator will light orange. Power On/Off To turn the LED LCD Monitor on/off: Press POWER button on the front of LED LCD Monitor. The power LED indicator lights green when the LED LCD Monitor is on. Using the OSD Menu You are able to use OSD menus to adjust various settings by using menu button on the front of the LED LCD Monitor.
Option 2: OSD & Power button lock – all 5 buttons including the “POWER” button are locked. Press and hold the 1 button and the ▼ button for 3 seconds to lock all 5 buttons. The LED LCD Monitor will show an “Lock Out” message for 5~10 seconds and the message will disappear automatically. Repeat this step to unlock.
Advanced Operation—OSD Menu You can use the OSD menu to adjust various settings for your LED LCD Monitor. Press the 1 button to display the OSD Menu, and use ▲▼ to select the desired OSD menu. Short Cuts Function from the button(s) Auto Image Adjust: To auto adjust Horizontal Position, Vertical Position, Phase (Fine Tune) and Clock (H. Size) of the screen. Contrast: To adjust the foreground white level of screen image. ▲: increase contrast, ▼: decrease contrast.
User Color: Individual adjustments for red (R), green (G), blue (B). 1. Press button 2 to select the desired color. 2. Press ▼ or ▲ button to adjust selected color. Information: To display the information, regarding the current input signal coming from the graphic card in your computer. Note: See your graphic card user guide for more information about changing the resolution and refresh rate. Manual Image Adjust: To manually adjust the Horizontal Size, H. /V.
OSD Position: Press ▼ or ▲ button to select between horizontal and vertical OSD Position adjustment. H. Position: To horizontally adjust the OSD position. ▲: move OSD to the right, ▼: move OSD to the left. V. Position: To vertically adjust the OSD position. ▲: move OSD up, ▼: move OSD down. OSD Time Out: To automatically turn off On Screen Display (OSD) after a preset period of time. OSD Background: Allows the user to turn the OSD background On or Off.
Supporting Timing Modes STANDARD VGA VGA MAC VESA VESA VESA VESA VESA VESA MAC VESA VESA VESA VESA VESA MAC VESA VESA VESA VESA CVT VESA VESA VESA RESOLUTION 720 x 400 @ 70Hz 640 x 480 @ 60Hz 640 x 480 @ 67Hz 640 x 480 @ 72Hz 640 x 480 @ 75Hz 800 x 600 @ 56Hz 800 x 600 @ 60Hz 800 x 600 @ 72Hz 800 x 600 @ 75Hz 832 x 624 @ 75Hz 1024 x 768 @ 60Hz 1024 x 768 @ 70Hz 1024 x 768 @ 75Hz 1280 x 960 @ 60Hz 1152 x 864 @ 75Hz 1152 x 870 @ 75Hz 1280 x 1024 @ 60Hz 1280 x 1024 @ 75Hz 1440 x 900 @ 60Hz 1440 x 900 @ 75Hz 1
Technical Information Technical Specification Panel 23.6” TFT (with LED back light) Power Management On: 35 Watts (typical), 40 Watts (maximum) Standby Mode: < 0.5 Watt Off: < 0.5 Watt Displayable Resolution Full HD 1920 x 1080 max. Vertical Frequency 60Hz max. Pixel Dimension 0.2715x 0.2715 mm Display Color 16.7M Tilt 0°~ 20° Active Display Area 521.38mm ×293.
Wall-mount instruction Preparing To Install The Optional Wall Mount Arm (not included) This LED LCD Monitor can be attached to a wall mounting arm you can purchase separately. Turn the power OFF then disconnect the cables from the LED LCD Monitor before performing the procedure below. 1. Lay the LED LCD Monitor face down on a soft surface. 2. Remove the hinge cover. 3. Remove the one screw holding the stand to the hinge. 4. Remove the stand.
Care and Maintenance Care Avoid exposing your LED LCD Monitor directly to sunlight or other heat source. Place your LED LCD Monitor away from the sun to reduce glare. Put your LED LCD Monitor in a well ventilated area. Do not place any heavy things on top of your LED LCD Monitor. Make certain your LED LCD Monitor is installed in a clean and moisture-free area. Keep your LED LCD Monitor away from magnets, motors, transformers, speakers, and TV sets.
Product Support Cables, Replacement Lamps, Accessories To find cables, replacement lamps and accessories for your Planar projector, LCD monitor, LED LCD Monitor, touch screen or other Planar products visit our online store at www.PlanarOnline.com or find other stores who carry Planar products at http://www.planar.com/howtobuy Technical Support Visit Planar at http://www.planar.
2012 P/N:2001171243T
