Preface This manual is designed to assist users in setting up and using the Integrated Thin Client Network Display (Network Display). Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. This document contains proprietary information protected by copyright. All rights are reserved.
Important Safety Instructions Please read the following instructions carefully. This manual should be retained for future use. 1. To clean the Network Display screen; -- Power off the Network Display and unplug the AC Cord. -- Spray a non-solvent cleaning solution onto a soft cloth. -- Gently clean the screen with dampened cloth. 2. Do not place the Network Display near a window. Exposing the display to rain water, moisture or sunlight can severely damage it. 3. Do not apply pressure to the LCD screen.
Installation Unpacking Before unpacking the Network Display, prepare a suitable workspace for your Monitor and computer. You need a stable and clean surface near a wall power outlet. Make sure that Network Display has enough space around it for sufficient airflow. Though the Network Display uses very little power, some ventilation is needed to ensure that the Monitor does not become too hot.
Alternate Mounting Solutions Detaching Network Display from Its Stand Unscrew screws n the swivel base support column and pull downo the hinge to release. Figure 1-3 Interface for Arm/ Wall Mount Applications Before installing to mounting device, please refer to Fig.1-3. The rear of this LCD display has four integrated 4 mm, 0.7 pitch threaded nuts, as well as four 5 mm access holes in the plastic covering as illustrated in Figure 1-4.
Connecting User Devices 1. USB devices such as the Keyboard can be connected to ports on the side or bottom (See Fig. 1-6 and Figure 1-7) 2. The unit may be secured through the use of Kensington locking devices. (See Figure 1-6) 3. The Headset/Handset port (RJ22) is reserved for future use with VOIP software support tools. It is designed for connection to analog telephone headsets or handsets. We recommend only the use of a UL or other safety agency approved device.
Display Controls User Controls A brief description and the location of all Network Display functions controls and indicators: 5 4 1 3 2 Figure 2-1 Power Control - LED 1 Modes are changed by pressing the Power Control Button (Please refer to Figure 2-2) 2 Brightness Function / Adjust increase 3 Brightness Function / Adjust decrease 4 Audio Volume Function / Adjust increase 5 Audio Volume Function / Adjust decrease 7
Power Modes The Network Display has three modes of operation. Figure 2-2 The following assumes the AC Power Adapter is connected to the display and an AC power source.
Technical Information Specifications LCD Panel Size Display Type Resolution Display Dot Aspect Ratio Display Area , mm (H x V) Displayed Colors Brightness Contrast Ratio Response Time Color Temperature ND1750 17" SXGA Active matrix color TFT LCD 1280 x 1024 1280 x (RGB) x 1024 5:4 337.92 mm (H) x 270.34 mm (V) Up to16.2M with FRC or Dithering 300 cd/m2 (typical) 800:1 (typical) 5ms (typical) 6500°K, Factory Calibrated ND1950 19” SXGA Active matrix color TFT LCD 1280 x 1024 1280 x (RGB) x 1024 5:4 376.
External Connections Power Input (DC input) GigaBit Ethernet port USB ports Headphone Microphone Headset DC Socket, 12V, 5A (Center Positive) RJ45 4 x USB connectors, Type A Receptacles 3.5mm Stereo Jack 3.
Troubleshooting This Network Display has been pre-adjusted using factory standards. PROBLEM There is no image on Network Display If there’s no image on the Network Display, please perform the following steps: 1. Verify that the power cord is connected to a proper source of power. 2. Verify that the power cord is fully connected to the Power Adapter and that the Power Adapter cord is fully connected to the DC connector on the rear of the Display. The LED on the Power Adapter should be green. 3.
