PR5020 Projector HOW TO PROGRAM BY RS232 www.planar.
Rev. 00 How To Program By RS232 Projection Display Serial Interface 6-1 RS232 Setting Baud rate: 9600 Parity check: None Data bit: 8 Stop bit: 1 Flow Control None Minimum delay for next command: 1ms 6-2 Control Command Structure The command is structured by the Header code, command code, data code and end code. Most of the commands are structured except some for the compatibility issue with other projectors.
Rev. 00 Input Select Wireless ~ S W CR 7Eh 53h 57h 0Dh * Power On command will not work for 1 minute after the power off command triggered. CR : Carriage Return. 6-5 Remote Command The remote commands simulate the code send from IR remote handset.
Rev. 00 6-6.
Rev. 00 6-7.
Rev. 00 6-8. Hyper Terminal setting guide 6-8-1 Connect the RS232 Cable between your computer and Projector。 6-8-2 Open HyperTerminal ， Window2000/XP HyperTerminal path： Start \ Programs \ Accessories \ Communications \ HyperTerminal。 6-8-3 Setting the HyperTerminal parameter： Step 1. Type the connection name .
Rev. 00 Step2 . Choose the COM port for your RS232 Cable connected to. Step3.
Rev. 00 Step4. Click the File and choose Properties to setting Keyboard parameter。 Step5. In Setting page , choose Emulation type for your keyboard.
Rev. 00 Step6. Click ASCII Setting icon to setup ASCII code parameter. Step7. Mark Send Line ends with line feeds and Echo typed characters locally and click OK bottom to complete setting.
