User Manual
2
ENGLISH
THIS PACKAGE CONTAINS
1 - PATV85 All-Terrain Speaker System
1 - Bluetooth Multi-Function Controller
1 - Handlebar Mounting Kit
1 - Quick Connect Power Extension Adaptor
4 - Hi-strength Nylon Mounting Straps
1 - User Manual
1 - Warranty Card
Thank you for purchasing this
PATV85 Bluetooth All-Terrain Sound System
Please read through these instructions carefully so you will know how to
operate your model properly.
After you have nished reading the instructions, keep this document in a
safe place for future reference.
All trademarks and trade names are those of their respective owners.
BEFORE YOU START
IMPORTANT SAFETY PRECAUTIONS
■ BE SURE TO OBSERVE THE FOLLOWING GUIDELINES:
- Do not turn up the volume so high that you can’t hear what’s around you.
- Use caution or temporarily discontinue use in potentially hazardous situations.
■ Do not operate mobile video equipment while driving a motorized vehicle – safe
driving and safety consideration of others should always be your highest priority.
■ Set your volume control at a low setting, then slowly increase the sound until you
can hear it comfortably without distortion, or ear discomfort.
■ In the event you should notice smoke, strange noises or odor from this
product, or any other abnormal signs, immediately turn o the power and consult
your dealer or the nearest authorized PLANET AUDIO Service Center. Using this
product in this condition may result in permanent damage to the system.
INSTALLATION PRECAUTIONS
WARNING - Always consult with a professional installer
■ Do not attempt to install or service this product by yourself. Installation or
servicing of this product by persons without professional training and experience in
electronic equipment and motorized vehicle accessories may be dangerous and
could expose you to the risk of electric shock, injury or other hazards
■ Refer any repairs to a qualied PLANET AUDIO Service Center
■ The PATV85 should be powered directly to a vehicles battery
■ When wiring directly to the vehicles battery, be sure to disconnect the batteries
negative terminal wire before starting any wiring procedures,if extending the main
power wire, it is suggested that an optional fuse and fuse holder (not included) with
minimum rating of 20 Amperes be in-line with the positive battery terminal
■ The ground cable length should not exceed 18-inches (See wiring diagram pg 3)
■ The PATV85 has a weather resistant design, it should not be submerged in or
under water under any circumstances
■ Use only the installation parts provided with the PATV85
CAUTION!! Using other mounting methods may void this warranty
USER MANUAL
QUICK START GUIDE
WARRANTY
CARD
