User Manual

9
10
ENGLISH
ENGLISH
MULTIFUNCTION CONTROLLER BLUETOOTH OPERATION
1) Press the
4
PLAY/PAUSE once to start playing music or press the PLAY button from
your device touch screen, press again to PAUSE
2) To skip songs or advance, press the NEXT TRACK
5
3) To select the previous song, press the PREVIOUS TRACK
6
VOLUME CONTROL
1) To raise the VOLUME press UP
2
button
2) To lower the VOLUME press DOWN
1
button
STREAMING MUSIC
1
2
Tips:
EN
Nyne Cruiser
USB CHARGE
5V 1A
Tips:
EN
Nyne Cruiser
USB CHARGE
5V 1A
6
5
4
YOUR DEVICE
Turn the BLUETOOTH volume level on your device to it’s 100% level
Tips:
EN
Nyne Cruiser
USB CHARGE
5V 1A
AUX-IN OPERATION
PATV85 can play audio from any device that has a 3.5mm headphone audio jack.
1) Power on the PATV85 by pressing and holding down the MFC POWER
7
button for
2 seconds
2) Connect the 3.5mm AUX-IN on the MFU to a 3.5mm adaptor
10
(3.5mm adaptor is not included)
3) The controller LED lighting will automatically change to RED, indicating the system is in
AUX-IN mode
4) Bluetooth devices will remain paired even in AUX-IN MODE
5) Route the audio wires back to a convenient stowage place, secure your device
VOLUME CONTROL
1) To raise the VOLUME press UP
2
button
2) To lower the VOLUME press DOWN
1
button
3) To MUTE / UN-MUTE the VOLUME press PLAY/PAUSE
4
button
AUX-INPUT
YOUR DEVICE
Turn the HEADPHONE volume level on your device to it’s 100% level
Tips:
EN
Nyne Cruiser
USB CHARGE
5V 1A
YOUR CABLE
10
7
1
2
6
5
4
