Completely Secure Wireless Network
The WBS-502AC supports 152-bit WEP, WPA/WPA2, WPA-PSK and WPA2-PSK wireless encryptions, the
advanced WPA2-AES mechanism and 802.1X RADIUS authentication, which can effectively prevent
eavesdropping by unauthorized users or bandwidth occupied by unauthenticated wireless access. Furthermore,
any users are granted or denied access to the wireless LAN network based on the ACL (Access Control List)
that the administrator pre-established. To provide the secure Wi-Fi access for visitors, Guest Network feature
allows you to create a temporary network with an individual SSID, security setting and DHCP settings to isolate
the guest network to a separate network segment, thus preventing guests from being able to access files on
intranet and also ensuring the guest's internet connectivity.
Deployment and Alignment within Minutes
In order to provide accurate antenna alignment, the WBS-502AC is equipped with a 360-degree 3D array of
mounting brackets, greatly reducing deployment effort to easily achieve high-performance backhaul links over
long distance through the built-in higher gain antenna.
Smart Management Features Meeting High Expectations
With user-friendly Web UI and comprehensive management features like RSSI threshold, Client Limit Control
and Wireless Traffic Shaping, the WBS-502AC is easy to limit the client access and control the bandwidth,
even for users who have no experience in setting up a wireless network. Furthermore, with the Planet Smart
Discovery Utility, SNMP and diagnostics tools, the WBS-502AC is convenient to be managed remotely.
1.3 Product Features
 Industrial Compliant Wireless LAN and LAN
 Compliant with the IEEE 802.11a/n/ac wireless technology
 2T2R architecture with data rate of up to 900Mbps
 Equipped with two 10/100/1000Mbps RJ45 ports with auto MDI/MDI-X supported
 IPv4 and IPv6 dual-stack management networks
 Fixed Network Broadband Router
 Supported WAN connection types in WISP mode: DHCP, Static IP, PPPoE, PPTP
 Supports Port Forwarding and DMZ for various networking applications
 Supports DHCP server in WISP mode
 Supports Guest Network in AP mode
 RF Interface Characteristics
 Built-in dual-polarization antenna
 High output power for outdoor usage
