Figure 4-6 Wireless Client List
The page includes the following settings:
Object Description
• SSID:#
The SSID number that the client is associated with.
• MAC Address
The MAC address of the associated client.
• Tx (Bytes)
The current transmit packet of the associated client.
• Rx (Bytes)
The current received packet of the associated client.
• RSSI (dBm)
The current signal strength of the associated client.
• Kick
Click Kick to add the client to the MAC ACL denied list.
4.2.4 WDS Link List
Click “Overview

Connections” to view the current WDS link client.
The WDS Link List is only available in WDS AP and WDS Bridge modes.
Figure 4-7 WDS Link Status
The page includes the following settings:
Object Description
• WDS Link ID
The sequence number of the WDS link.
• MAC Address
The MAC Address of the associated remote node.
• Link Status
The current link status.
• RSSI (dBm)
The current signal strength of the associated remote node.
