User Manual of WBS-502AC
-31-
Figure 4-10 LAN IP Settings
The page includes the following settings:
Object Description
• IP Network Setting
Select Obtain an IP address automatically (DHCP) to receive the IP
from DHCP server.
Select Specify an IP address to configure the AP to use static IP.
• IP Address
The LAN IP of the AP.
The default is 192.168.1.253. You can change it according to your needs.
• IP Subnet Mask The LAN subnet mask of the AP.
• Default Gateway
Enter the Gateway IP address of the AP.
• Primary DNS Enter the primary DNS server of the AP.
• Secondary DNS
Enter the secondary DNS server of the AP.
• Use Link-Local Address
Click to enable a link-local address for the AP.
• IPv6 IP Address
Enter the IPv6 LAN IP of the AP.
• IPv6 Subnet Prefix Length
Enter the secondary DNS server of the AP.
• IPv6 Default Gateway
Enter the IPv6 Gateway IP address of the AP.
• IPv6 Primary DNS
Enter the IPv6 primary DNS server of the AP.
• IPv6 Secondary DNS
Enter the IPv6 secondary DNS server of the AP.
• Save
Click Save to apply the new settings.
