4.3.2 Spanning Tree Settings
The Spanning Tree Protocol (STP) allows network to provide a redundant link in the event of a link failure.
Click “Network

Basic” to enable/disable Spanning Tree Settings.
Figure 4-11 Spanning Tree Settings
The page includes the following settings:
Object Description
• Spanning Tree Status
Click Enable to enable or click Disable to disable the option.
• Hello Time
Specify Hello Time in seconds. This value determines how often the AP
sends hello packets to communicate information about the topology
throughout the entire Bridged Local Area Network.
• Max Age
Specify Max Age in seconds. If another bridge in the spanning tree does
not send a hello packet for a long period of time, it is assumed to be dead.
• Forward Delay
Specify Forward Delay in seconds. Forwarding delay time is the time
spent in each of the Listening and Learning states before the Forwarding
state is entered. This delay is provided so that when a new bridge comes
onto a busy network, it looks at some traffic before participating.
• Priority
Specify the Priority number. Smaller numbers have greater priority.
• Save
Click Save to save the setting.
4.4 Router (WISP Mode Only)
4.4.1 DHCP Server Settings
Go to the “Network

Wireless” page to configure the device as “WISP” and then go to “Router

LAN
Settings” to configure the device’s LAN IP settings.
On this page, enable the DHCP server to assign IP address to local wired/wireless clients after the device is
connected to the remote AP supplied by wireless ISP.
