User Manual of WBS-502AC
-40-
• #
Displays the sequence number of the forwarded port.
• Name
Displays the name of the forwarded port.
• Protocol
Displays the protocol to use for mapping from the following: TCP, UDP or
Both.
• Start Port
Displays the LAN port number that WAN client packets will be forward to.
• End Port
Displays the port number that the WAN client packets are received.
• Server IP Address
Displays the IP address of the server for the forwarded port.
• Enable
Click to enable or disable the forwarded port profile.
• Modify
Click to modify the forwarded port profile.
• Delete
Click to delete the forwarded port profile.
• Add Entry
Click Add Entry to add the new forwarding rule.
• Save
Click Save to save the setting.
When clicking Add Entry, the following window pops up and fill in the fields required to add a new forwarding
rule.
Figure 4-20 Port Forwarding
The page includes the following settings:
Object Description
• Service Name
Enter a name for the port forwarding rule.
• Protocol
Select a protocol for the application: Choices are TCP or UDP, or both.
• Starting Port (1~65535)
Enter a starting port number.
• Ending Port (1~65535)
Enter an ending port number.
All ports numbers between the starting and ending ports will forward
users to the IP address specified in the IP Address field.
