1.2 Product Description
Ultra-high-speed Enterprise Outdoor Wireless Solution
PLANET WBS-502AC 5GHz 900Mbps 802.11ac Outdoor Wireless CPE supports IEEE 802.11ac standard with
2T2R MIMO mechanism, which brings the latest wireless technology into outdoor infrastructure. The
WBS-502AC supports standard IEEE 802.3at Power over Ethernet (PoE) and features IEEE 802.3af PoE
pass-through going to the secondary LAN port, which is able to supply power to the PoE IP camera or other
PoE PD equipment. With excellent performance and concentrated antenna beamwidth, the WBS-502AC is
definitely ideal for long-distance outdoor surveillance.
Bringing Superior 11ac Performance to Outdoor
To provide extremely high-speed user experience, the WBS-502AC adopts IEEE 802.11ac technology to extend
the 802.11n 40MHz channel binding to 80MHz and the implementation of 256-QAM modulation where higher
transmitting/receiving rates go up to 867Mbps in 5GHz frequency band with less interference. Equipped with
Gigabit LAN ports, the WBS-502AC allows 11ac wireless traffic to directly access high-speed connection
without the bottleneck of 100Mbps uplink wired connection, thus offering a better range and superior throughput
than those of the 802.11a/n wireless outdoor CPE.
Multiple SSIDs with VLAN Tagging
Multiple SSIDs can broadcast up to 8 wireless networks with different names. For management purposes, the
IEEE 802.1Q VLAN supported allows multiple VLAN tags to be mapped to multiple SSIDs to distinguish the
wireless access or allows VLAN tags to pass through over WDS link. This makes it possible for the WBS-502AC
to work with managed Ethernet switches to have VLAN assigned for a different access level and authority.
Value-added Outdoor Characteristics
The WBS-502AC is definitely suitable for wireless IP surveillance, and bridge link of building to building and
backbone of public service. With standard IEEE 802.3at Power over Ethernet (PoE) design, the WBS-502AC
can be powered by the remote PoE switch through the 100m Cat5e UTP cable and is able to supply power to the
IP camera supporting IEEE 802.3af standard through the secondary LAN port. With the IP55-rated outdoor
UV-resistant enclosure, the WBS-502AC can perform normally under rigorous weather conditions, meaning it
can be installed in any harsh, outdoor environments.
