SWP-0412G2 Series L2 Web Smart Switch User Guide Table of Contents UNPACKING INFORMATION ..................................... 4 INTRODUCTION........................................................ 4 GENERAL DESCRIPTION ............................................................................ 4 KEY FEATURES ......................................................................................... 4 THE FRONT PANEL ....................................................................................
SWP-0412G2 Series L2 Web Smart Switch User Guide STATISTICS OVERVIEW ........................................................................... 25 DETAILED STATISTICS ............................................................................. 25 RESTART ................................................................................................. 26 FACTORY DEFAULT ................................................................................. 26 SMART BOOT .........................................
SWP-0412G2 Series L2 Web Smart Switch User Guide Unpacking Information Congratulations on purchasing this 16-port Gigabit Web Smart Switch with 4 Mini-GBIC Combo slots. Before you start, please verify that your package contains the following items: 1. 2. 3. 4.
SWP-0412G2 Series L2 Web Smart Switch User Guide The Front Panel The front panel features all the LED indicators and ports: Device LED: LED Power (PWR) Status Steady Green Off Operation The switch is powered on The switch is powered off Port LEDs: LED 1000M 10/100M Status Operation Green The port is connected at 1000 Mbps Blinking Green A valid link is established, and there is data transmitting/receiving.
SWP-0412G2 Series L2 Web Smart Switch User Guide Port Operation The auto-negotiation feature allows ports to run at one of the following operation modes: Media 10/100/1000Mbps(copper) Speed 10Mbps 100Mbps 1000Mbps(Fiber) (mini GBIC required) 1000Mbps 1000Mbps Duplex Mode Full Duplex Half Duplex Full Duplex Half Duplex Full Duplex Full Duplex Note: For the interchangeable (combo) ports (the last 4 RJ-45 ports and the fiber slots), if both the fiber and copper interfaces of an interchangeable pair (comb
SWP-0412G2 Series L2 Web Smart Switch User Guide Installation This Switch can be placed on your desktop or mounted in a rack. Installation is very easy. Users can use all the features of the Switch by simply attaching the cables and turning the power on. Before installing the Switch, we strongly recommend that … 1. … the Switch must be placed in an environment that is well ventilated – a minimum space around the unit of 25mm is recommended. 2.
SWP-0412G2 Series L2 Web Smart Switch User Guide Description of Switch Functions Jumbo Frame The Switch supports Jumbo Frames, which means that it can transmit the same data in fewer frames. This helps to ensure fewer overheads, shorter processing time, and fewer interruptions. NOTE: To enable Jumbo Frame, Flow Control should be enabled in advance. Flow Control and Backpressure Flow Control and Backpressure both help devices with different processing speeds to communicate with each other.
SWP-0412G2 Series L2 Web Smart Switch User Guide Management guide Access the Switch This section shows you how to access and use the Switch’s advanced management capability, which can be accessed via console port or Internet Browser over the network (in-band). Manage via Command Line Interface To start the Command Line Interface, please connect a PC COM port to the RS-232 connector and activate a terminal emulation software (e.g.
SWP-0412G2 Series L2 Web Smart Switch User Guide Homepage After successful log-in, the “SYSTEM Configuration” page appears (this is also the Homepage). You can click on the hyperlinks on the left side of each page to get access to each management function.
SWP-0412G2 Series L2 Web Smart Switch User Guide System The System window provides the Switch’s system information and allows users to configure most of these properties (see table under screenshot for details). Items MAC Address S/W Version IP Address Subnet Mask Gateway Management VLAN User Name Password System Name Functions The MAC address of this device.. The software version of this device.
SWP-0412G2 Series L2 Web Smart Switch User Guide Note: After applying a new IP address, a new log-in page will appear automatically. Please log in again to proceed to other configurations. Port This Port Configuration page shows the link status of each port and allows users to configure speed, flow control and maximum frame size for each port. Items Link Mode Flow Control Functions Shows the link status of each port.
SWP-0412G2 Series L2 Web Smart Switch User Guide Max Frame length Adjust the size of Jumbo Frames. The default is 1518 bytes. The Maximum value can be up to 9k bytes. To save the configuration of the system, click “Apply”. You can also click the “Refresh” button to show the updated statuses of the ports.
SWP-0412G2 Series L2 Web Smart Switch User Guide VLAN VLAN divides the network members into groups to reduce packet collisions and improve the network efficiency. The switch supports 802.1q tag-based VLAN. Please follow the instructions to configure. To add new VLAN groups, 1. Fill in a VLAN ID, from 2 to 4094, in the “VLAN\Port” column. 2. Select the ports for each VLAN group. 3. Click the “Apply” button to execute. To delete a VLAN group 1.
SWP-0412G2 Series L2 Web Smart Switch User Guide PVID When the VLAN-enabled Switch receives a tagged packet, the packet will be sent to the port’s default VLAN according to the PVID (port VLAN ID) of the receiving port. Items Port Egress Functions Port Number 1~16 Select “tagged” in the drop menu to enable the PVID checking and tag inserting of one port, and select “untagged” to cancel. For example, if an Egress-tagged port receives an untagged frame, it will be transmitted as a PVID tagged frame.
SWP-0412G2 Series L2 Web Smart Switch User Guide Aggregation/ Trunk Configuration To set up the port trunk groups, put the selected ports’ numbers into the same Aggregation group. You can choose up to eight groups. Don’t forget to click “Apply” to save the settings. There are three aggregation modes for you to set up, SMAC, DMAC, and XOR. SMAC mode selects the path of packets according to Source MAC while DMAC mode selects path according to Destination MAC.
SWP-0412G2 Series L2 Web Smart Switch User Guide Quality of Service QoS enhances communication quality by giving precedence to certain classes of packets.
SWP-0412G2 Series L2 Web Smart Switch User Guide Port-based mode QoS: Port-based QoS allows users to configure each port as having a high or low priority. To assign a priority level to each port: 1. 2. 3. 4. Select “Port” in the “Mode” column for those ports that are going to function as part of port-based QoS. Click the “Apply” button. Click the “Port priority” button. The “Port Priority Setting” appears. Click on the drop menu to specify priority levels. Click “Apply” to execute.
SWP-0412G2 Series L2 Web Smart Switch User Guide Tag-based QoS: Tag-based QoS assigns packet priority according to the tags on the packets. To configure Tag-based QoS: 1. 2. 3. 4. 5. Select “Tagged” in the “Mode” column for those ports that are going to perform tag-based QoS. Click the “Apply” button. Click the “Tag priority” button. The “Tag Priority Setting” page shows up. Select the port that you are going to configure from the drop menu. Set the priorities as high or low for each Priority Tag type.
SWP-0412G2 Series L2 Web Smart Switch User Guide DSCP-mode QoS: DSCP-mode QoS assigns packet priority according to the types of the incoming packets. It distinguishes packets according to the “Delay”, “Throughput” and “Reliability” information attached to the packet. The types are listed as the following: Bit 0 (Delay) 0 (Normal) 1 (Low) Bit 1 (Throughput) 0 (Normal) 1 (High) Bit 3 (Reliability) 0 (Normal) 1 (High) Note: The Switch distinguishes packets with DSCP precedence “000(routine)” only.
SWP-0412G2 Series L2 Web Smart Switch User Guide Mirror The Mirror function copies all the packets that are transmitted by the source port to the destination port. It allows administrators to analyze and monitor the traffic of the monitored ports. Mirror Configuration: 1. 2. 3. Select those ports that are going to be monitored by marking the checkboxes in the “Monitor Port” column. Click the drop menu in the “Sniffer Port” column. Select a port as the administration port for monitoring those source ports.
SWP-0412G2 Series L2 Web Smart Switch User Guide Rate Limit The “Rate Limit” page allows users to limit the bandwidth for each port and configure the rules for Storm Control, which limits the flow of broadcast and multicast To perform storm control: 1. 2. Click on each drop list to specify a speed for each frame type. Click the “Apply” button to execute your configuration.
SWP-0412G2 Series L2 Web Smart Switch User Guide SNMP This device supports SNMP-management, which allows network administrators to monitor and configure this device with SNMP software. To allow this device to be managed via SNMP: 1. 2. 3. 4. Select “enable” in the drop menu. Specify a trap IP. A trap IP is the destination port for sending trap information, which is usually the IP address of network administrators.
SWP-0412G2 Series L2 Web Smart Switch User Guide Discovery After installing a series of our switches, the discovery management tool helps users to search and get access to those switches within the LAN. Note: The discovery tool lists a maximum of 16 devices respectively for auto and manual modes. Auto Search 1. Click the “Apply” button to start. 2. The devices being found are listed below. 3. Click the IP address hyperlink to get access to the device. Manual Add Add 1.
SWP-0412G2 Series L2 Web Smart Switch User Guide Statistics Overview The Statistics Overview is provided for users to see the general transmitting and receiving status of each port. You may click the “Clear” button to clean all statistics or click the “Refresh” button to renew the statistics. Detailed Statistics The Detailed Statistics is provided for users to see the detailed transmitting and receiving status of each port. Please click the hyperlinks above to select a port.
SWP-0412G2 Series L2 Web Smart Switch User Guide Restart Restart: To restart the system, click the “Yes” button. The system restarts and shows the authentication window. Please fill in the username and password to continue. Factory Default Restore Factory Default: To restore the factory default settings, click the Yes button. Note: The IP address of the device will also be reconfigured to the factory default setting, which is 192.168.1.254.
SWP-0412G2 Series L2 Web Smart Switch User Guide Software Upload This “Software Upload” page allows users to upgrade firmware for this Switch. To perform firmware upgrade: 1. Click the “Browse” button 2. Locate the firmware file 3. Click the “Upload” button to execute. Note: This new firmware is going to be applied on the remaining flash that you have NOT selected in “Smart Boot”, that is, the new firmware is going to be applied on the flash that is NOT chosen as the booting flash.
SWP-0412G2 Series L2 Web Smart Switch User Guide Appendix- Command Line Interface Start-up and Terminal configuration To start the Command Line Interface, please connect a PC COM port to the RS-232 connector and activate a terminal emulation software (e.g. Windows’ HyperTerminal) The terminal emulation software should be started in the following configuration: 1. Data rate: 115200 baud 2. Data format: 8 data bits, 1 stop bit and no parity 3. Flow control: none. 4.
SWP-0412G2 Series L2 Web Smart Switch User Guide Command Hierarchy After logging in, press ? + to show the 9 command groups. System Console Port VLAN Aggr QoS Mirror IP SNMP Ratelimit Exit - System commands - Console commands - Port commands - VLAN commands - Aggregation commands - QoS commands - Mirror commands - IP commands - SNMP commands - Rate setup commands - Logout commands Press ? or help to get help.
SWP-0412G2 Series L2 Web Smart Switch User Guide Command Description These are the group commands of the command line interface: Command groups: System - System commands Console - Console commands Port - Port commands VLAN - VLAN commands Aggr - Aggregation commands QoS - QoS commands Mirror - Mirror commands IP - IP commands SNMP - SNMP commands Ratelimit - Rate setup commands Exit - Logout commands System Commands Commands at System level: System Configuration [all] System Restore Default [keepIP] Syste
SWP-0412G2 Series L2 Web Smart Switch User Guide []: String of up to 16 characters (default: Show system name). System Reboot Description: Reboot the switch. Console Commands Commands at Console level: Console Configuration Console Timeout [] Console Prompt [] Console Configuration Description: Show configured console prompt and timeout Console Timeout [] Description: Set or show the console inactivity timeout in seconds. The value zero disables timeout.
SWP-0412G2 Series L2 Web Smart Switch User Guide Port Commands Commands at Port level: Port Configuration [] Port Mode [] [] Port Flow Control [] [enable|disable] Port Admin [] [enable|disable] Port MaxFrame [] [|reset] Port Statistics [] [clear] -----#Note: If you want to make maxframe bigger than 1518, the [Flow Control] should be enabled! Port Configuration [] Description: Show the configured and current speed, duplex
SWP-0412G2 Series L2 Web Smart Switch User Guide Port Admin [] [enable|disable] Description: Set or show the admin state for the port. [] : Port list (default: All ports). [enable|disable]: Enable or disable admin state (default: Show admin state). Port MaxFrame [] [|reset] Description: Set or show the maximum frame size in bytes (including FCS) for frames received on the port. Tagged frames are allowed to be 4 bytes longer than the maximum frame size.
SWP-0412G2 Series L2 Web Smart Switch User Guide VLAN Commands Commands at VLAN level: VLAN Configuration [] VLAN Add [] VLAN Delete VLAN Lookup VLAN Egress [] [untagged|tagged] VLAN PVID [] [|none] VLAN OnlyTag [] [enable|disable] VLAN Configuration [] Description: Show the VLAN egress mode, port VLAN ID and accepted frame type for the port and the permanently stored VLAN table.
SWP-0412G2 Series L2 Web Smart Switch User Guide VLAN Egress [] [untagged|tagged] Description: Set or show the VLAN egress mode setting for the port. Egress untagged ports will strip the VLAN tag from received frames. Egress tagged ports will not strip the tag from received frames []: Port list (default: All ports). [tagged|untagged]: (default: Show egress tag setting). VLAN PVID [] [|none] Description: Set or show the port VLAN ID.
SWP-0412G2 Series L2 Web Smart Switch User Guide Aggregation Commands Commands at Aggr level: Aggr Configuration Aggr Add Aggr Delete Aggr Lookup Aggr Mode [smac|dmac|xor] Aggr Configuration Description: Shows the aggregation groups and the aggregation mode. Aggr Delete Description: Delete link aggregation group. : Port list. Aggregations including any of the ports will be deleted.
SWP-0412G2 Series L2 Web Smart Switch User Guide QoS Commands Commands at QoS level: QoS Configuration [] QoS Mode [] [tag|port|diffserv] QoS Port [] [] QoS Tagprio [] [] [] QoS DiffServ [] [] range: low|normal|medium|high QoS Configuration [] Description: Show the configured QoS mode and the priority setting of all ports. []: Port list (default: All ports).
SWP-0412G2 Series L2 Web Smart Switch User Guide QoS DiffServ [] [] Description: Set or show the IP Differentiated Services mapping. []: IP DSCP number, 0-7. [] : range: low|normal|medium|high Mirror Commands Commands at Mirror level: Mirror Configuration Mirror Port [] Mirror Source [] [enable|disable] Mirror Configuration Description: Show the mirror destination port and mirror mode for source ports.
SWP-0412G2 Series L2 Web Smart Switch User Guide IP Commands Commands at IP level: IP Configuration IP Setup [ [ []]] [] IP Web management [enable|disable] IP Configuration Description: Show IP configured IP address, mask, gateway, VLAN ID and mode. IP Setup` Description: Setup or show IP configuration. []: IP address. (default: Show IP configuration) [] : IP subnet mask (default: Subnet mask for address class).
SWP-0412G2 Series L2 Web Smart Switch User Guide Ratelimit Commands Commands at Ratelimit level: Ratelimit Configuration Ratelimit Setup
SWP-0412G2 Series L2 Web Smart Switch User Guide Ratelimit Egress [] [enable|disable] [] Description: Set or show the egress configuration. [] [enable|disable] [] : Port list (default: All ports). : Enable or disable egress. : Disable or set leaky bucket rate in Kbit/s [128/256/512/1024/2048/3072k] (default: Show egress rate). Ratelimit Ingress[] [enable|disable] [] Description: Set or show the ingress configuration.
SWP-0412G2 Series L2 Web Smart Switch User Guide Product Specifications Standard IEEE802.3 10BASE-T IEEE802.3u 100BASE-TX IEEE802.3x full-duplex operation and flow control IEEE802.3ab/z 1000BASE-T IEEE802.1Q VLAN interoperability IEEE802.
