7” Portable DVD Player PDV-0700 Operation Manual 20040928
Contents Safety Precautions ..................... 3 ■ Title Menu ............................. 17 Precautions with Moisture .......... 5 ■ Previous and Next................. 17 Function Features ...................... 6 System Setup ............................. 18 Parts Introduction ....................... 7 ■ General Setup....................... 18 Remote Control .......................... 8 ■ Speaker Setup ...................... 19 Connections ...............................
Important Safety Instructions CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be sufficient to constitute a risk of electric shock to persons.
Important Safety Instructions 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use near water. 6. Clean only with dry cloth. 7. Do not block any ventilation IMPORTANT FOR LASER PRODUCTS 1. CLASS 1 LASER PRODUCT 2. DANGER: Visible laser radiation when open and interlock failed or defeated. Avoid direct exposure to beam. 3. CAUTION: Do not open the top cover. There are no user service-able parts inside the unit.
Precautions with Moisture Under the following circumstances, moisture may appear on the lens of the product, which is the most sensitive part of the DVD player: - The DVD player is suddenly moved from a cold place to a warm place. - A room is heated while the DVD player starts operating, or the DVD is placed by an air-conditioner. - In the hot summer season, the DVD player is moved from an air-conditioned room to a hot, damp place to be used. - The DVD player is being operated in a damp place.
Function Features 1. EXCELLENT SOUND Memorizes and continues playing from Dolby Digital delivers great sound. 2. HIGH RESOLUTION place stopped. MPEG2 decoding format achieves more On-screen displays in your choice14 0 0 7.98 433.62404 6P487 672.84007 than 500 lines of horizontal resolution. 3.
Parts Introduction DVD Player 1. OPEN button 13. PREV SKIP button 2. Remote sensor 14. Speaker 3. Disc cover 15. Bright up/down 4. Indicator: Lights red when the power 16. Color up/down 17. TFT Liquid Crystal Display switch is on. 5. Indicator: Lights green when the 18. Earphone/speaker volume knob player is in operation. 19. Earphone jack 6. ENTER button 20. Audio output/input jack 7. Direction buttons 21. Video output/input jack 8. TITLE button 22.
Remote Control -8-
Remote Control 9. NEXT SKIP button 17. -Press to go to next chapter. 10. SUBT button press PLAY button to resume normal -When a DVD is playing, press to select playback. a subtitle language or to turn subtitles -Press the button twice to stop playback off. 11. completely. ANGLE button 18. -Press to access various camera angles (if the DVD disc contains multiple camera 19. A-B button time, track or title. 20. between A and B.
Connections Connecting to a TV Audio/video connections 1. Always ensure that the DVD player, TV and any other electrical equipment you are connecting the DVD player to is switched off and unplugged from the power supply. 2. The easiest way to connect the DVD player to a television is via the supplied Audio/Video connections.
Playback Preparations Using the Remote Control 1. Referring to the drawing above, remove the empty battery receptacle. 2. Prior to shipping, a separating film was applied to the battery. Remove this film. 3. Press the battery into the receptacle and insert the receptacle into the remote. 4. For best results, aim the remote directly at the player’s receiving window from a range no greater than 15 feet, and at angles no greater than 60 degrees. 5. Under normal use the battery will last for one year.
Playback Preparations Disc Formats Supported by this Player The unit can play discs bearing any of the following logos: DISC LOGO DIAMETER PLAYBACK TIME/ PLAYABLE SIDES 133 min 12cm DVD (SS-SL) 242 min (SS-DL) 266 min (DS-SL) 484 min (DS-DL) 41 min (SS-SL) 8cm 75 min ( SS-DL ) 82 min (DS-SL) 150 min 12cm 74 min 8cm 20 min 12cm 600 min (DS-DL) CD MP3 The operating method of some DVD discs is specified by the software maker. Please refer to the instruction manual of the disc.
Playback Preparations - 13 -
Power Supply Using and Charging the Battery Pack Charge the Battery Pack before using it the first time. Charging time is normally 3-4 hours. Do not charge the Battery Pack more than 4 hours as it could reduce service life. Normally, the Battery Pack can be charged approximately 300 times. When fully charged, the Battery Pack delivers 3-4 hours of continuous power. Battery Pack should be fully charged before initial use! 1. Attaching the Battery Pack Turn the player upside down on a smooth, clean surface.
Detaching Battery Pack Detaching Battery Pack from the unit: If the player is not going to be used for a long period of time, we recommend that you detach the Battery Pack. Even if the unit is powered down, the unit is still consuming some power in STANDBY mode. This will discharge the battery. Make sure the power is turned off before detaching the Battery Pack. After detaching the battery pack, take care when handling the unit. 1. Slide the tab and hold in position.
Basic Operation Please read these instructions carefully before using your player for the first time. 1. Turn on the player’s power by switching the POWER switch on the side of the player to “ON”. 2. Press OPEN button on front panel to open the disc cover. 3. Remove the lens cover. 4. Load disc with the label facing up to prevent damage to the player or disc. 5. Close the disc cover. The player will automatically search for the disc and when it finds it, play will begin.
Basic Operation Stop During playback, press the STOP button on the remote control to stop playing. Press the PLAY button again and the player will play from the point where it stopped. Mode During playback, press the mode button on the control panel to change the aspect ratio on the screen. Title Menu 1. 2. 3. 4. Press the TITLE button on the remote control during payback. The title menu will appear on the TFT screen.
System Setup GENERAL SET-UP You can change the default settings to customize performance to your own preference. 1. Remove the disc from the DVD drive and press the ‘SETUP’ button on the remote control, the settings menu will appear. It includes General Setup, Speaker Setup, Dolby Digital Setup, Video Setup and Preference setup. 2. Press (direction buttons) on the remote control to select a category. 3. All the items in the category will appear on the TV screen.
System Setup 3. OSD Language There are five kinds of different OSD languages for selection. You can select it according to your preference. 4. SPDIF Output This item is used to set the format of digital audio. ‘SPDIF OFF’ turns off the digital audio; ‘SPDIF/RAW’ outputs the original. For example, if the disc being played is Dolby Digital, then the digital audio output is also Dolby Digital. 5. Captions You can choose captions on or off on screen during playback. 6.
System Setup Video Setup 2. Brightness Use this item to adjust brightness level. 3. Contrast Use this item to adjust contrast level. Preference Page 1. Audio, Subtitle, Disc Menu This setting allows you to hear or read subtitles of a DVD in your choice of English, Spanish or French. 2. Default Reset Use this function to reset all the settings. 3. Version Displays software version information. NOTE: this menu function is not available while a disc is playing.
Playback Functions Fast Forward & Rewind Press the and buttons to fast forward or rewind. Slow Forward & Rewind Press the SLOW button to slow forward or rewind. Repeat 1. Repeat a title, chapter or track. Press the REPEAT button on the remote control. Pressing the REPEAT button repeatedly will display a menu as follows: Chapter, Title and All. 2. You can temporarily mark a section of a DVD that you would like to play repeatedly. Do this by marking the start and end of the section using the A/B button.
Playback Functions Search by time You can use the GOTO button to search by time - 22 -
Playback Functions Playing a JPEG JPEG is a common picture format that requires very little storage per image with a low loss rate in resolution. Hundreds of pictures can be stored on a disc in this format. In order to create digital albums from film pictures, have your film developer make a ”PICTURE CD”, in JPEG format. OPERATION 1. Normal Playback Load a JPEG disc in. After reading the disc, OSD will display the menu (the left side is the main menu and the right side is its submenu).
Care of Discs How to hold discs When loading or removing discs, do not touch their playing surfaces. Cleaning Care Use a soft, dry cloth for cleaning. For stubborn dirt, soak the cloth in a mild detergent solution. Use a dry cloth to wipe the disc dry. Do not use any volatile agents such as benzine or paint thinner, as they may damage the surface of the disk.
About the Rechargeable Battery Your portable DVD player comes with a lithium ion rechargeable battery that attaches to the bottom of the player. 1. Under normal working conditions, the battery can be charged and discharged over 300 times. 2. The properties of the rechargeable battery are: 7.4 Volts, with a capacity of 4200mAh, interior lithium ionic electric circuit protection for recharge and discharge. 3. If the battery is not used it will gradually discharge within one month. 4.
Troubleshooting SYMPTOM WHAT TO CHECK The player cannot play. -Make sure the disc cover is closed. -Make sure the AV IN/OUT switch on the side of the player is in the OUT position for standard play -Make sure a disc is loaded. -Make sure the disc isn’t loaded upside down. -Disc should be clean, not dirty or warped. -Player’s region code should be the same as region code of DVD disc. -Has water condensation has occurred? If it has, remove the disc and keep the player powered up for at least two hours.
Specifications TFT screen size 7 inches Laser Wavelength Wavelength: 780/650nm Video System NTSC Frequency Response 20Hz～20kHz ±2.5dB Audio Signal-to-noise Rate 85dB Audio distortion + noise -70dB (1kHz) Channel Separation 70dB (1kHz) Dynamic Range 80dB (1kHz) 0.2 1.0 Analog Audio Out Out Level: 2V ± Digital Audio Out Out Level: 0.5VP-P, , Load: 10k Audio Out Out Level:1VP-P ± 0.2, Video Out Video Out Power AC100-240V～50/60Hz Power Consumption 25W Dimension w/o battery 7.
For service, support and warranty information, visit www.polaroidelectronics.com or in the US call 1-866-289-5168, in Canada call 1-866-301-7922 and in Mexico call 01-800-400-2443. “Polaroid” is a registered trademark of Polaroid Corporation of Waltham, MA USA and licensed for use on the PDV-0700 to Petters Consumer Brands, LLC.
