4GB Music & Video Player with 3.
In the box USB 2.0 Cable 4GB Music & Video Player with 3.5” Touch Display PMP350-4 User Guide Customer Support: 1-877-768-8483 (Toll Free) polaroidsupport@southerntelecom.com www.polaroid.com Polaroid and Polaroid & Pixel are trademarks of PLR IP Holdings, LLC, used under license. PLR IP Holdings, LLC does not manufacture this product or provide any Manufacturer’s Warranty or support.
FCC Information FCC Part 15 This equipment has been tested and found to comply with the requirements for a Class B digital device under Part 15 of the Federal Communications Commission (FCC) rules. These requirements are intended to provide reasonable protection against harmful interference in a residential installation.
Introduction Congratulations on purchasing an Polaroid MP3 Player. This manual contains important safety information and correct operation instructions. Before using the player, read this manual thoroughly and keep it for future reference. Copyright Information Trademarks and trade names used in this instruction manual are owned by their respective companies or organizations.
Important safety precautions Always follow these basic safety precautions when using your player. This will reduce the risk of damage to the product and personal injury. Do not disassemble, repair or modify the player by yourself. Refer servicing to qualified personnel. This device contains a built- in battery, do not dispose of in fire. In the event that the battery is leaking, do not handle the device with your bare hands. Contact the service center for help since the liquid may remain in the player.
Features 3.5” Touch screen 4 GB internal memory Built-in stereo speaker USB 2.
Location of controls 5 1. [ POWER ] - Power ON/Off switch / lock 2. Microphone 3. Mini-USB jack 4. Headphone jack □ - Select an option / Return / Menu 6. Touch Screen display 7. Speaker (listen to music or video without headphones) 8. Reset hole 1 2 3 4 8 MIC 5.
Connecting to a computer System requirements You computer system must meet the following specifications: Pentium 200MHz or above Microsoft Windows 2000/ME/XP/Vista USB port supported PC USB High Speed Connection Cable MP3 Player PC connection In order to enjoy the multimedia capabilities of your MP3 Player, you must first copy your favorite files from your PC to it’s internal memory. Connect your MP3 Player to the computer using the included USB 2.0 cable.
Disconnecting the USB cable After completing the file transfer, please disconnect the USB cable the following way: 1. Double click the green arrow “Safely Remove Hardware” in the task bar on the bottom right of the window. 2. Select “USB Device” and click “Stop”. 3. When the “Stop a Hardware device” appears, click “OK” to disconnect the USB mass storage device, and unplug the player safely.
Charging the battery Your MP3 Player has an integrated rechargeable Li-ion battery. It is recommended to fully charge the player before using it for the first time. Recharge the battery by connecting the player to a computer using the included USB 2.0 cable. Charging time is between 3-5 hours, depending if the player is powered off or working. To keep the battery in good condition, we recommend not charging it for more than 8 hours. A fully charged battery will give approximately 6 hours of playback time.
Basic operation Turning on/off [POWER] switch ON / OFF Slide the switch this way and HOLD until the player turns on or off Make sure the player is charged, and the headphones are connected correctly. ● To turn on the player, slide and HOLD the [ POWER ] switch to the left until the display turns on. ● To turn the player off, slide and HOLD the [ POWER ] switch to the left until the display turns off.
Transferring media to the player The MP3 Player is capable of storing, displaying, and playing your favorite music, pictures, and video. music pictures video MP3 Player Find your music, picture, or video files on your computer Transferring media to the player Connect the MP3 player to your computer, and locate “MP3” . Drag the files into the area shown below. Emerson MP3 To transfer media from your computer, perform the following steps: 1. Connect the MP3 player to the USB port of your computer. 2.
Main menu Once you turn on the player, the main menu will appear. You may also use the or □ button to return to the main menu from the other modes. 1. Touch the icon you wish to select: “music”, “video”, “photos”, “record”, “browser”, “settings”. 2. Touch an option and press the □ button. 3. Touch and HOLD the or □ button to go back to the main menu.
music Store and playback your favorite songs and organize them by playlists, atrist, and other options. See “TRANSFERRING MEDIA TO THE PLAYER” (page 12) and follow the steps below to transfer, playback and organize your music. 1. Select “music” from the main menu. 2. touch “Current Play” to enter the music playback status. Press the □ button. 3. touch the icon to terurn to the previous menu. 4. touch the icon again to exit the submenu and return to the main interface. 5.
Adjusting the volume Touch the volume bar to adjust the volume. Music player settings Touch the icon or press the □ button to enter the submenu while playing music. Slick to select the submenu you want. Touch the return to the previous menu. Repeat Mode: Once, Repeat, All, All repeat, Intro. Play Mode: In order, Shuffle. MSEQ (PlayFX): 3D, Bass, LEQ. EQ Selection: Normal, MSEQ, Rock, Pop, Classic, Bass, Jazz, User EQ. User EQ Setup: To set your favorite EQ in the menu.
video 1. Select “video” from the main menu. 2. Touch the video file you would like to watch, and double-touch to begin playback. NOTE: Use the [ ▲] or [ ▼] buttons from the scroll bar to move to the next or previous page of files or folders. icon to return to the file list while playing , and then double- touch the corresponding 3. Touch the file to playback. Playing videos While in the video playback status, touch the icon to pause. Touch the icon to resume play.
photos Viewing pictures The MP3 Player is capable of storing and displaying your favorite pictures. See “TRANSFERRING MEDIA TO THE PLAYER” (page 12) and follow the steps below: 1. Select “photos” from the main menu. 2. Double-touch a photo file you wish to view. 3. Touch icon or press the □ Enter button to pop-up the submenu while browsing pistures. 4. Touch the menu “ Rotate Right” / “Rotate Left” / “ Zoom out” / “Browse” to realize the corresponding settings. 5.
Deleting Files ● From the player 1. Select “browser” from the main menu. 2. Touch the file you wish to delete. 3. Press the button and then touch “Delete File” to confirm and delete the file. OR ● From your computer You can easily delete music, picture, or video files by connecting your MP3 Player to the computer and selecting “MP3” from Windows Explorer or “My Computer”, or click on “Open Folder” to view files from the “AutoPlay” option window.
settings The player’s settings can be customized by accessing “settings” in the main menu. The settings menu consists of several items where various functions can be selected concerning music, power, language, display, recording, system, etc. Navigating the settings menu 1. 2. Select “settings” from the main menu. Touch the corresponding setting item to enter it. ● Display Setting ●System Setting ● Desktop ● Language ● System information ● AutoShutTime ● Explorer 3. Select the option, and press the 4.
Troubleshooting If you have problems while operating your player, please check the points below before sending it to the service center Can not power on The battery may be exhausted, please recharge the battery Files can not be transferred to the player Check if the driver is installed correctly in the computer by disconnecting and then reconnecting the player to the computer Check the connection between the player and PC, and confirm the USB cable is properly connected No sound from the headphones
Specifications Display 3.5” touch screen display Connect with PC USB 2.
Limited warranty In the unlikely event that this product is defective, or does not perform properly, you may within ninety (90) days from your original date of purchase return it to the authorized service center for repair or exchange. TO OBTAIN WARRANTY SERVICE: - Provide proof of the date of purchase within the package (Dated bill of sale) - Prepay all shipping costs to the authorized service center, and remember to insure your return. - Include a return shipping address (no P.O.
To obtain service after the warranty period, please e-mail polaroidsupport@southerntelecom.com with product information, date of purchase and nature of the problem. Customer service will reply to the e-mail with service instructions. Warranty service not provided: This warranty does not cover damage resulting from accident, misuse, abuse, improper installation or operation, lack of reasonable care, and unauthorized modification.
“Polaroid” and “Polaroid and Pixel” are registered trademarks of Polaroid Corporation, used under license. Microsoft, the Windows logo, and Windows Media are either registered trademarks of Microsoft Corporation in the United States and / or other countries.
