VIEW Certified Configuration Guide Trapeze Networks Mobility System for MP-422 Access Points June 2008 Edition 1725-36060-001 Version D
Configuration Guide Trademark Information Notice Polycom® and the logo designs SpectraLink® LinkPlus Link NetLink SVP Are trademarks and registered trademarks of Polycom, Inc. in the United States of America and various countries. All other trademarks used herein are the property of their respective owners. Polycom, Inc. has prepared this document for use by Polycom personnel and customers.
Trapeze Networks: Mobility System for MP 422 Access Points Introduction Polycom’s Voice Interoperability for Enterprise Wireless (VIEW) Certification Program is designed to ensure interoperability and high performance between SpectraLink Wireless Telephones and wireless LAN (WLAN) infrastructure products. The products listed below have been thoroughly tested in Polycom’s lab and have passed VIEW Certification.
Configuration Guide Service Information The AP must support SpectraLink Voice Priority (SVP). Contact your AP vendor if you need to upgrade the AP software. If you encounter difficulties or have questions regarding the configuration process of the Mobility Exchange, please contact Trapeze Networks by calling 866 TRPZ TAC or 925 474 2400 or by e-mailing support@trapezenetworks.com. Known Limitations During VIEW Certification testing, the following limitations were discovered.
Trapeze Networks: Mobility System for MP 422 Access Points Network Topology The following topology was tested during VIEW Certification. It is important to note that these do not necessarily represent all “Certified” configurations. Both Layer-2 and Layer-3 roaming were tested. Layer-3 roaming of SpectraLink Wireless Telephones requires the use of a generic routing encapsulation (GRE) tunnel.
Configuration Guide Access Point Setup and Configuration Installing software Trapeze Mobility Exchange firmware cannot be downloaded from the SpectraLink website. Therefore, you must use the software that was shipped with your product, or contact Trapeze Networks for the latest software release. Command, comment, and screen text key In the sections below you will find commands, comments and system responses or other screen-displayed information involved in the configuration process.
Trapeze Networks: Mobility System for MP 422 Access Points Service profile commands (SSID & security policy setup) WPA2-PSK Assume you are creating service profile “vowlan-wpa2” to define the ESSID “phones,” as well as a WPA2-PSK security policy.
Configuration Guide # defines a passphrase set service-profile Voice auth-psk enable # enables pre-shared key authentication set service-profile Voice auth-dot1x disable # disables 802.1x authentication set service-profile Voice attr vlan-name default # maps the handsets to the vlan named default Radio profile commands Assume you are creating radio profile “voice” for all radios that will be providing voice services.
Trapeze Networks: Mobility System for MP 422 Access Points Radio configuration During VIEW Certification, the MP access points were tested directly connected to a port on the MX (e.g. port 1). The following commands will configure a specific access point’s radio to support the voice service: set ap 1 radio 1 mode disable # if the radio is currently enabled. Radio 1 is the 802.
Configuration Guide Subnet roaming configuration between multiple MX switches To set up subnet roaming between two switches, a mobility domain must be configured on both switches. Choose one of the switches to be the “seed” switch. The IP addresses used in mobility domain configuration must use the system IP address of each switch). The following commands are performed on the seed MX switch: set system ip-address 1.1.1.1 set mobility-domain mode seed domain-name set mobility-domain member 1.
Trapeze Networks: Mobility System for MP 422 Access Points Checking the configuration Once the switch is configured, issue the following command at the command prompt to check the SVP settings: sh ap qos-stats The following information should be displayed (repeat the command to see changes): CoS Queue Tx =========================== port: 1 radio: 1 1,2 Background 0 0,3 BestEffort 604 4,5 Video 0 6,7 Voice 79106 1,2 0,3 4,5 6,7 port: 1 radio: 2 Background BestEffort Video Voice # Voice should have the m
Configuration Guide Configuration File (For Reference Only) The following configuration file was used during VIEW Certification testing. The configuration below includes all configuration attributes, including defaults. Use the command show configuration all for this detailed version. To only see non-default configuration values, use the command show configuration. Note: All of the lines below are commands, except for those preceded by the # symbol, which denotes a comment.
Trapeze Networks: Mobility System for MP 422 Access Points set service-profile VoWLAN-WPA wep active-multicastindex 1 set service-profile VoWLAN-WPA wpa-ie disable set service-profile VoWLAN-WPA rsn-ie enable set service-profile VoWLAN-WPA cipher-tkip enable # for WPA this should be disabled set service-profile VoWLAN-WPA cipher-ccmp enable # for WPA this should be enabled set service-profile VoWLAN-WPA cipher-wep104 disable set service-profile VoWLAN-WPA cipher-wep40 disable set service-profile VoWLAN-WPA
Configuration Guide set radio-profile RealRadio auto-tune power-backofftimer 10 set radio-profile RealRadio active-scan disable set radio-profile RealRadio qos-mode svp set radio-profile default 11g-only disable set radio-profile default beacon-interval 100 set radio-profile default dtim-interval 1 set radio-profile default max-tx-lifetime 2000 set radio-profile default max-rx-lifetime 2000 set radio-profile default rts-threshold 2346 set radio-profile default short-retry 5 set radio-profile default long-r
Trapeze Networks: Mobility System for MP 422 Access Points set ap 2 name MP02 set ap 2 bias high set ap 2 blink disable set ap 2 upgrade-firmware enable set ap 2 group none set ap 2 radio 1 channel 6 tx-power 2 radio-profile default mode disable set ap 2 radio 1 auto-tune max-power default min-clientrate 5.
Configuration Guide set spantree uplinkfast disable set spantree fwddelay 15 vlan 1 set spantree hello 2 vlan 1 set spantree maxage 20 vlan 1 set spantree priority 32768 vlan 1 set spantree disable vlan 1 set igmp disable vlan 1 set igmp proxy-report enable vlan 1 set igmp querier disable vlan 1 set igmp mrsol disable vlan 1 set igmp version 2 vlan 1 set igmp mrsol mrsi 30 vlan 1 set igmp qi 125 vlan 1 set igmp oqi 255 vlan 1 set igmp qri 100 vlan 1 set igmp lmqi 10 vlan 1 set igmp rv 2 vlan 1 set igmp mro
