Use and Care Guide

ManualsBrandsPortfolio ManualsPendant Light Conversion KitsMPA-2JBZ

ITEM #0404278

0404279

MODEL #MPA-2JBZ

MPA-2PNK

Français p. 8

Español p. 15

Portfolio® is a registered trademark

RECESSED LIGHT CONVERSION KIT

ATTACH YOUR RECEIPT HERE

Serial Number

Purchase Date

Questions, problems, missing parts? Before returning to your retailer, call our customer

service department at 1-800-643-0067, 8 a.m. - 6 p.m., EST, Monday - Thursday, 8 a.m. -

5 p.m., EST, Friday.

XXXXXX

Lowes.com/

ortfolio

Summary of content (7 pages)

PAGE 1
ITEM #0404278 0404279 Portfolio® is a registered trademark of LF, LLC. All Rights Reserved. RECESSED LIGHT CONVERSION KIT MODEL #MPA-2JBZ MPA-2PNK Français p. 8 Español p. 15 ATTACH YOUR RECEIPT HERE Serial Number Purchase Date Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-800-643-0067, 8 a.m. - 6 p.m., EST, Monday - Thursday, 8 a.m. 5 p.m., EST, Friday. XXXXXX Lowes.
PAGE 2
PACKAGE CONTENTS PART A DESCRIPTION Fixture B Socket Ring (preassembled to fixture (A)) QUANTITY A B 1 1 SAFETY INFORMATION READ AND SAVE THESE INSTRUCTIONS. Please read and understand this entire manual before attempting to assemble, operate or install the product. DANGER • For your protection and safety, carefully read and understand the information provided in this manual completely before attempting to assemble, install or operate this product.
PAGE 3
SAFETY INFORMATION WARNING • All electrical connections must be in agreement with local codes and ordinances, the National Electric Code (NEC) and ANSI/NFPA 70-1999. Contact your municipal building department to learn about your local codes, permits and/or inspections. Risk of fire – most dwellings built before 1985 have supply wire rated for 140°F. Consult a qualified electrician before installation.
PAGE 4
ASSEMBLY INSTRUCTIONS 1. Turn off circuit breakers and wall switch to the fixture supply line leads. 1 DANGER: Failure to disconnect power supply prior to installation may result in serious injury or death. 2. Remove existing fixture and disconnect all electrical wiring. ON ON OFF OFF 2 Existing Recessed Light Fixture 3. Loosen cord restraint under canopy on fixture (A) to allow canopy to move down the cord. 3 A Canopy Cord Restraint Lowes.
PAGE 5
ASSEMBLY INSTRUCTIONS 4. Loosen cord vice on socket assembly with a screwdriver to adjust cord length. Pull cord through until at proper length, and then tighten cord vice with screwdriver to hold cord at desired length. Do not overtighten vice as it may damage the wires inside the cord. 4 Socket Assembly Cord Vice Cord 5. Screw socket assembly at top of fixture (A) into recessed light fixture socket. 5 Recessed Light Fixture Socket Assembly A 6.
PAGE 6
ASSEMBLY INSTRUCTIONS 7. Remove socket ring (B) from socket on fixture (A). Attach glass shade (not included) with socket ring (B). 7 7A 6 A NOTA: Do not overtighten socket ring (B) as glass may crack or break. Socket Glass Shade [representative only] D B 8. Install one standard-base 60-watt max. bulb (not included). *Maximum wattage for fixture (A) is 60 watts--PLEASE NOTE WARNINGS BELOW.
PAGE 7
CARE AND MAINTENANCE • Shut off main power supply. Wipe with soft cloth or use window cleaner. Do not use an abrasive cleaner. • Bulb Replacement: Use 60-watt max. standard-base bulb. TROUBLESHOOTING WARNING: Before beginning work, shut off the power supply to avoid electrical shock. PROBLEM Bulb will not light. POSSIBLE CAUSE 1. Bulb is burned out. 2. Power is OFF. 3. Faulty connection. CORRECTIVE ACTION 1. Replace light bulb. 2. Make sure power supply is ON. 3. Check wiring and all connections.
